Key Features - HP Visualize j6000 Supplementary Manual

Product Information
Product Description

Key Features

The J6000 workstations have the following key features.
• CPUs:
— Two 552MHz PA-8600 microprocessors, each with 0.5 MB instruction cache and 1.0
MB data cache.
• Operating System (Native HP-UX):
— 32-bit support requires HP-UX version 10.20 plus the June 1999 Workstation ACE
(Additional Core Enhancements)
— 64-bit support requires HP-UX version 11.0 plus ACE 9911
• User Interface: HP CDE (Common Desktop Environment) graphical user interface
• Compatibility: Source- and binary-code compatible with the B
product families
• Main Memory: Using 512MB or 1 GB DIMMs
— Sixteen DIMM slots in pairs (from 1GB up to 16GB total)
• Power Supply:
— 500 Watt (output power), 715 Watt (input power) with two VRM modules
• Remote Power-On
— Remote power-on feature that allows you to power up and shut down your
workstation remotely through the RS232 port.
• Internal Storage Devices:
— Up to two Low-Voltage Differential (LVD) SCSI hard drives.
— One optional ATAPI Slim-line CD drive.
• Standard Networking: Ethernet IEEE 802.3 RJ45, Twisted Pair 10/100 Base T
• Standard I/O: Two GB/sec. aggregate I/O bandwidth
— Two low-voltage differential (LVD) SCSI buses. One dedicated to the two internal
disk drives and one for the external devices (multi-mode).
— Two USB (Universal Serial Bus) connectors (keyboard and mouse)
— Two serial interface connectors (RS-232C)
— Audio connectors (line input, line output, headphone, and microphone)
12
, C-, and J-Class
-
Chapter 1
