RIGOL
2) Rotate the multifunction knob
The character is displayed in the English selection area.
3) In the English selection area, rotate the multifunction knob
and press it down. Then, "F" is displayed in the name input area, "F" is input
successfully. If the character is not found in the current page, press
go to the next page until you find the desired character.
4. Input the Other Characters
Use the same method to input the remaining letters "ilename" by referring to
Step 3. Pay attention to the upper-lower case of the letters when inputting them.
5. Modify or Delete the Unwanted Characters that Have Been Entered.
While entering a filename, you can modify or delete the unwanted character if
necessary. To delete the input characters, rotate the multifunction knob
the virtual keypad to select the delete key
characters. To modify the input characters, delete the unwanted characters and
input the desired characters again. If the character to be modified is in the
middle, press the delete key
one to the character to be modified, then input the new character again.
If the touch screen is enabled, tap to directly move the cursor to the character
required to be modified or deleted, and then input the desired character again
or delete the unwanted character.
Tip
If characters already exist in the letter input area, when you rotate the
multifunction knob
characters in the letter input area will be deleted first.
6. After finishing the input, rotate the multifunction knob
oscilloscope will create a folder or a specified type of file with this name under
the current directory.
Simplified Chinese (or Traditional Chinese) Input Method
For example, create a folder with the name "文件名". Note that the input method of
traditional Chinese is the same as that of the simplified Chinese.
18-12
to select "F" and press down the knob.
to delete the characters starting from the last
to delete the characters in the name input area, the
Chapter 18 Store and Load
. Press down the key to delete the
and press OK. The
MSO7000/DS7000 User Guide
to select "F"
to
in
