User Dip Switches (Active High); User Push Buttons (Active High) - Xilinx ML623 User Manual

Chapter 1: ML623 Board Features and Operation
Table 1-9: User LEDs (Cont'd)

User DIP Switches (Active High)

[Figure
The DIP switch SW7 provides a set of eight active-High switches that are connected to user
I/O pins on the FPGA as shown in
any other purpose determined by the user.
Table 1-10: User DIP Switches

User Push Buttons (Active High)

[Figure
SW5 and SW6 are active-High user push buttons that are connected to user I/O pins on the
FPGA as shown in
the user.
Table 1-11: User Push Buttons
20
FPGA Pin Net Name
F15 LED3
G15 LED4
B15 LED5
A15 LED6
G16 LED7
F16 LED8
1-2, callout 15]
FPGA Pin Net Name
M17 SW1
M18 SW2
J19 SW3
K19 SW4
B17 SW5
C17 SW6
L18 SW7
L19 SW8
1-2, callout 16]
Table 1-11. These switches can be used for any purpose determined by
FPGA Pin Net Name
E31 PB_SW1
F31 PB_SW2
www.xilinx.com
Reference
Designator
DS15
DS14
DS13
DS12
DS11
DS10
Table 1-10. These pins can be used to set control pins or
Reference
Designator
SW7
Reference
Designator
SW6
SW4
UG724 (v1.1) September 15, 2010
ML623 Board User Guide
