Monitoring Voltage and Current
Voltage and current monitoring and control are available for selected power rails through
Texas Instruments' Fusion Digital Power graphical user interface (GUI). Both onboard TI
power controllers are wired to the same PMBus. The PMBus connector, J6, is provided for
use with the TI USB Interface Adapter PMBus pod and associated TI GUI.
References
More information about the power system components used by the ML623 board are
available from the Texas Instruments digital power website at:
http://www.ti.com/ww/en/analog/digital-power/index.html

GTX Transceiver Power Module

The GTX transceiver power module supplies MGTAVCC and MGTAVTT voltages to the
FPGA GTX transceivers. Three power modules are provided with the ML623 board. Any
one of the three modules can be plugged into connectors J34 and J179 in the outlined and
labeled power module location shown in
X-Ref Target - Figure 1-4
Table 1-2
rails. It also lists the maximum current ratings for each rail supplied by either module
included with the ML623 board.
Table 1-2: GTX Transceiver Power Module
Power Supply Typical
Rail Net Name Voltage
Technology
MGTAVCC 1.025V
MGTAVTT 1.2V
The GTX transceiver power rails also have corresponding input voltage jacks to supply
each voltage independently from a bench-top power supply (See External Supply Jack
column in
ML623 Board User Guide
UG724 (v1.1) September 15, 2010
Figure 1-4: Mounting Location, GTX Transceiver Power Module
describes the nominal voltage values for the MGTAVCC and MGTAVTT power
Maximum Current Rating
Linear Texas
Instruments
Module Module
20A 10A
12A 6A
Table 1-2). To supply power externally to one or both rails when the Linear
www.xilinx.com
Figure 1-4.
Regulation Jumper
Linear
Intersil
Technology Instruments
Module
Module
10A JP1
6A JP2
Detailed Description
UG724_c1_04_031910
External
Texas
Intersil
Module
Module
N/A N/A
N/A N/A
Supply
Jack
J178
J189
