Important
• When loading a roll, be careful to avoid hitting the printer hard with the roll. This may damage the •
roll holder.
• • If you stand the roll holder vertically and set the roll paper by dropping, the roll holder may be
damaged.
4. 4. If using 3-inch core paper, align 3-inch paper core attachment tabs (A) with holder stopper
holes (B) and insert firmly.
5. 5. Insert holder stopper from left into roll holder as shown, and then while holding in position
(B), push firmly until holder stopper flange (A) touches roll paper. Lock the holder stopper
lever (C) by rotating it towards .
