Operation Panel

A: HOME button
The HOME screen appears.
Home Screen Menu Composition
B: Back button
Displays the screen before the current screen.
C: Stop button
Cancels print jobs in progress and ends the ink drying period.
D: ON button/ON lamp
Turns the printer on and off.
Turning the Printer On and Off
The ON lamp is lit when the printer is on or in Sleep mode.
E: Touch Screen
Shows printer menus, as well as the printer status and messages. You can select menu items and
display buttons by gently touching the screen with your fingertip.
Home Screen Menu Composition
F: Status lamp
• Flashing (white) •
During printing, this lamp flashes when the printer is receiving or processing print jobs. Otherwise,
this lamp flashes when the print job is paused or the printer is updating the firmware.
• Lit (orange) •
A warning message is displayed.
• Flashing (orange) •
An error message is displayed.
• • Off
There are no active print jobs, warnings, or errors.
