Lines or colors are misaligned

Adjust the position of the Print head
Check 1
If borders are misaligned or the print results are not uniform, adjust the position of the Print head.
Automatic Adjustment to Straighten Lines and Colors
Manual Adjustment to Straighten Lines and Colors
For photo paper and proof paper, it may be improved by setting Paper thickness (head height) to a value lower
than the current setting and then adjust the position of the Print head.
Troubleshooting Paper Abrasion and Blurry Images
Is the media type specified in the printer driver the same as the media type
Check 2
loaded in the printer?
When printing with the media type specified in the printer driver, load the specified media type in the printer.
Loading Rolls in the Printer
Loading Sheets in the Printer
When printing with the media type specified in the printer driver, load the specified media type in the printer.
1. 1. To stop printing, press the Stop button.
2. 2. Change the paper type in the printer driver and try printing again.
Note
• When Auto (Use Printer Settings) is selected for the media type, printing is performed with the media •
type loaded in the printer.
• Click Get Information to reflect the paper information set in the printer to the printer driver. •
Printing with Easy Setup
When loading paper in the printer, is the media loaded the same as the media
Check 3
type selected on the touch screen?
Select the correct media type in the touch screen menu when loading paper in the printer.
Loading Rolls in the Printer
