TECHNICAL
MANUAL
O O p p e e n n F F r r y y e e r r ( ( E E l l e e c c t t r r i i c c ) )
R R e e d d u u c c e e d d O O i i l l C C a a p p a a c c i i t t y y
LVE-202
LVE-203
LVE-204
FM06-044E

Advertisement

Table of Contents
loading

Related Manuals for Henny Penny LVE-203

Summary of Contents for Henny Penny LVE-203

  • Page 1 R R e e d d u u c c e e d d O O i i l l C C a a p p a a c c i i t t y y LVE-202 LVE-203 LVE-204 FM06-044E...

  • Page 3: Table Of Contents

    Table of Contents Safety..........................v Chapter 1 Troubleshooting ....................1 1.1 Introduction ......................1 1.2 Troubleshooting Guide ...................1 1.3 Error Codes ......................5 Solid State High Limit Change................8a - 8e Chapter 2 Info, Filter & Temp Button Stats.................9 2.1 Info Button Stats ....................9 2.2 Filter Button Stats ....................9 2.3 Temp Button Stats....................10 2.4 HP Info Mode.......................10...
  • Page 4 6.1 Info Mode ......................33 6.1.1 Filter Stats .....................33 6.1.2 Review Usage ....................33 6.1.3 Last Load ......................34 Chapter 7 Maintenance ....................35 7.1 Introduction ......................35 7.2 Maintenance Hints ....................35 7.3 Preventative Maintenance ..................35 7.4 Control Panel & Menu Card Replacement ..............35 7.4.1 Control Panel Replacement ................36 7.4.2 Menu Card Replacement................36 7.5 High Temperature Limit System................37 7.5.1 Checkout.......................37...
  • Page 5 7.18.1 Checkout.....................71 7.18.2 Replacement ....................72 7.19 Filter Motor Relay....................72 7.19.1 Replacement ....................72 7.20 Check Valve.......................73 7.20.1 Replacement ....................73 7.21 Drain Pan Switch....................73 7.21.1 Removal......................74 7.22 Filter & JIB Lights ....................75 7.22.1 Replacement ....................75 Chapter 8 W i r i n g D i a g r a m s ....................77...
  • Page 7 S S a a f f e e t t y y The Henny Penny unit has many safety features incorporated. However, the only way to ensure safe operation is to fully understand the proper installation, operation, and maintenance procedures. The instructions in this manual have been prepared to aid you in learning the proper procedures.
  • Page 9 C C h h a a p p t t e e r r 1 1 T T r r o o u u b b l l e e s s h h o o o o t t i i n n g g 1 1 .
  • Page 10 Problem Cause Correction Faulty drain Check drain switch per 7.21 Drain Pan Switch , page switch. Faulty PC board. Check control panel per 7.4.1 Control Panel Replace- ment , page 36 and replace as needed. High limit control Allow heating elements to cool down (15-20 minutes), re- tripped.
  • Page 11 Problem Cause Correction Cold zone (bot- Filter oil. tom of vat) full of crumbs. Improper rinsing Rinse the vat thoroughly to remove any cleaning agent in after cleaning the the vat. vat. Oil will not Drain valve Open valve, use straight white brush to force crumbs drain from clogged with through drain valve.
  • Page 12 Problem Cause Correction pumps oil Drain pan O-rings Install new O-rings. slowly. damaged or missing. Filter paper or Change filter paper or pad. pad clogged. Filter motor Power cord for Plug power cord into receptacle. will not run. vat #1 is not plugged-in.
  • Page 13 1 1 . . 3 3 E E r r r r o o r r C C o o d d e e s s In the event of a control system failure, the digital display shows an error message. The message codes are shown in the display column below.
  • Page 14 Display Cause Correction “E-18-B” Right level sen- checked at the control board; have sensor checked and sor open. replace if necessary. “E-18-C” Both level sen- sors open. “E-21” Slow heat Have a certified service technician check the fryer for cor- recovery.
  • Page 15 Display Cause Correction “E-82B” Home switch 5 5 . . Check for voltage at the motor connection AIF side. Is failed, Position there a voltage of 24VDC? if yes, replace motor. If no, switch working. check harness and AIF board. “E-82C”...

  • Page 16: 1.4 Solid State High Limit Change

    Technical Bulletin 1.4 Solid State High Limit Change Henny Penny is using a dual thermocouple SSHL (solid-state high limit) system for all fryers starting in 2021. This change is necessary to comply with updated agency approval standards. Dual thermocouple units are identified by orange, normally closed high limit reset switches. See Figure 1. for visual differences.
  • Page 17 Table 5 Theory of Operation Ref. Description The dual thermocouple SSHL (solid state high limit) shown in Figure 2, monitors N.O. Relay two J-type thermocouples. The cold junction of these thermocouples is connected Red “Limit” LED to terminals (D) and (E) and the hot junction is mounted at the heating element Amber “In-Range”...
  • Page 18 Troubleshooting E-10 high limit not resetting 1. If the high limit trips and can’t be reset, make sure that they vat has had at least 20 minutes to cool. If 20 minutes have passed, verify that the correct reset switch is being pressed and is being held in for 10 seconds. If the high limit still doesn’t reset, power down the controls so all LEDs on the main control panel are off.
  • Page 19 2. Limit and In-Range status LEDs are included on the dual thermocouple solid state high limit. Table 3 provides a definition for using the LEDs as diagnostic indicators relating to the high limit status and possible causes. 3. If the fryer has two solid state high limit controls per vat, either SSHL control may be open causing the fryer main control panel to display an E-10 error.
  • Page 20 FFF reset switch configuration SSS reset switch configuration SFF reset switch configuration SSSS reset switch configuration...
  • Page 21 C C h h a a p p t t e e r r 2 2 I I n n f f o o , , F F i i l l t t e e r r & & T T e e m m p p B B u u t t t t o o n n S S t t a a t t s s NOTE: If no buttons are pressed within 5 seconds in any of stat modes, the controls revert back to normal operation.

  • Page 22: Hp Info Mode

    2 2 . . 3 3 T T e e m m p p B B u u t t t t o o n n S S t t a a t t s s T T a a b b l l e e 2 2 - - 3 3 T T e e m m p p B B u u t t t t o o n n S S t t a a t t s s Menu Step Description Actual Oil...
  • Page 23 e e . . Vat-1 f f . . Vat-2 g g . . Vat-3 h h . . Vat-4 i i . . Vat-5 j j . . Vat-6 k k . . Vat-7 l l . . Vat-8 1 1 8 8 .

  • Page 25: Modifying Product Settings

    C C h h a a p p t t e e r r 3 3 L L e e v v e e l l 1 1 P P r r o o g g r r a a m m m m i i n n g g Level 1 contains the following: •...
  • Page 26 Press the down arrow until “COOK ID” shows in the display along with the 9 9 ) ) product ID. For example, “NUG” would be the ID for nuggets. Use the product buttons to change the ID, following the same procedure as Step 6 above. A A l l a a r r m m s s ( ( D D u u t t y y 1 1 &...
  • Page 27 Press the down arrow once and “AIF CLOCK” show in the displays. 3 3 ) ) Press ✓ button and use the left and right arrows to scroll through “ENABLE” and 4 4 ) ) “DISABLE” and then press ✓ button again to select one. If “ENABLE”...
  • Page 28 Press the down arrow 3 times and “FRYER SETUP” show in the displays. 3 3 ) ) Press ✓ button and “*SETUP* *MODE*” shows in the displays, followed by, 4 4 ) ) “LANGUAGE” on the left display, “ENGLISH” on the right display. Use the left and right arrows to change the operation display to, “FRANCAIS”, 5 5 ) ) “CAN FREN”, “ESPANOL”, “PORTUG”, “DEUTSCHE”, “SVENSKA”,...

  • Page 29: Advanced Product Settings

    C C h h a a p p t t e e r r 4 4 L L e e v v e e l l 2 2 P P r r o o g g r r a a m m m m i i n n g g Used to access the following: •...
  • Page 30 NOTE: • Use the up arrow button to go back to previous menu items. • Press “X” button when finished with the current product, to return to the PRODUCT SELECTN step. • Press “X” button a second time to exit PROD COMP mode. 4 4 .
  • Page 31 Enter code 1, 2, 3, 4 (first 4 product buttons). “PROD” and “COMP” show in the 2 2 ) ) displays. Press the down arrow 3 times and “ALERT TONE” shows in the display. 3 3 ) ) Press right ✓ button and “VOLUME” shows in the display, along with the volume 4 4 ) ) value.

  • Page 33: Chapter 5 Level 3 Programming

    C C h h a a p p t t e e r r 5 5 L L e e v v e e l l 3 3 P P r r o o g g r r a a m m m m i i n n g g Used to access the following: •...

  • Page 34: System Initialization

    T T a a b b l l e e 5 5 - - 1 1 S S p p e e c c i i a a l l P P r r o o g g r r a a m m M M o o d d e e s s Program Code Description S S P P - - 1 1...
  • Page 35 Description Program Code S S P P - - 3 3 4 4 Old Pad - Max. Fill Time - XXX SEC S S P P - - 3 3 5 5 Fill To Top Time - XXX SEC S S P P - - 3 3 6 6 Reach Top Plus x Seconds - XXX SEC S S P P - - 3 3 7 7 Fill Until Pan Empty - XXX SEC...
  • Page 36 S S P P - - 70 NOTE: Not all Special Program Mode functions are discussed in this section. To ensure proper operation of fryer, please consult Henny Penny Corp. before changing any of these settings. For information on these functions, contact Service Department at 1-800-417-8405, or 1-937-456-8405.

  • Page 37: Clock Set

    5 5 . . 2 2 . . 8 8 S S P P - - 8 8 E E d d i i t t U U n n i i t t S S e e r r i i a a l l N N u u m m b b e e r r Press the down arrow and “SP-8 S/N ✓EDIT”...

  • Page 38: Tech Mode

    5 5 . . 4 4 D D a a t t a a C C o o m m m m & & H H e e a a t t C C o o n n t t r r o o l l NOTE: Data communications and heat control settings are shown in Level 3 Program Mode. To ensure proper operation of fryer, please consult Henny Penny Corp. before changing any of these settigns. Fo more information on these functions, contact Service Department at 1-800-417-8405, or 1-937-456-8405.
  • Page 39 T T a a b b l l e e 5 5 - - 2 2 T T e e c c h h M M o o d d e e s s Program Code Description T T - - 1 1 S S o o f f t t w w a a r r e e 1 1 .
  • Page 40 Program Code Description T T - - 1 1 6 6 V V i i e e w w A A - - D D C C h h a a n n n n e e l l T T - - 1 1 7 7 D D i i g g i i t t a a l l I I n n p p u u t t s s •...
  • Page 41 Program Code Description • “P” - Drain Pan • “M*” - Drain pan missing. • “JL” - JIB • “J*” - JIB oil level is low. • “R” - RTI • “R*” - RTI system detected. • “DT” - RTI Discard Tank •...
  • Page 42 Program Code Description • Press product 7 to open and close the return valves. “DcRc” means valves are closed, “DoRo” means valves are open (driven by the control board). 2 2 . . Press the down arrow and “DISCARDc” and “JIBFILLc” shows in the displays (driven by the AIF board).
  • Page 43 Program Code Description • Press product 2 to turn off and on the JIB low light (display shows “JLO*” when on). T T - - 2 2 1 1 C C h h a a n n g g e e T T e e c c h h C C o o d d e e ? ? T T - - 2 2 2 2 T T o o t t a a l l I I n n i i t t i i a a l l i i z z a a t t i i o o n n 5 5 .
  • Page 44 Program Code Description S S T T - - 1 1 6 6 S S y y s s t t e e m m R R A A M M F F a a d d e e C C o o u u n n t t S S T T - - 1 1 7 7 C C o o o o k k R R A A M M F F a a d d e e C C o o u u n n t t S S T T - - 1 1 8 8...

  • Page 45: Chapter 6 Information Mode

    C C h h a a p p t t e e r r 6 6 I I n n f f o o r r m m a a t t i i o o n n M M o o d d e e 6 6 .
  • Page 46 6 6 . . 1 1 . . 3 3 L L a a s s t t L L o o a a d d Press ✓ button to select Last Load (ex: -P1- = Product 1; L1 = left, first product) 1 1 ) ) and press the up or down arrows to view the following.
  • Page 47 C C h h a a p p t t e e r r 7 7 M M a a i i n n t t e e n n a a n n c c e e 7 7 . . 1 1 I I n n t t r r o o d d u u c c t t i i o o n n This section provides checkout and replacement procedures for various parts of fryer.
  • Page 48 7 7 . . 4 4 . . 1 1 C C o o n n t t r r o o l l P P a a n n e e l l R R e e p p l l a a c c e e m m e e n n t t Remove electrical power supplied to the vat.
  • Page 49 Perform steps seven and eight of 7.4.1 Control Panel Replacement , page 36 3 3 ) ) 7 7 . . 5 5 H H i i g g h h T T e e m m p p e e r r a a t t u u r r e e L L i i m m i i t t S S y y s s t t e e m m A thermocouple is attached to each element and senses oil temperature.
  • Page 50 NOTE: Oil temp must be 380°F (193°C) to perform this check.
  • Page 51 Connect a known good high limit control into wiring for the suspect 5 5 ) ) thermocouple and control. Connect electrical power and operate vat. If vat does not overheat, replace 6 6 ) ) defective control with known good part. If vat overheats, perform more checkouts of other components (relays, 7 7 ) ) contactors, probes, etc.) and replace the heating element as the last resort.
  • Page 52 Element Resistance Element Total Watts System Watt System Resistance Part Watt Color Voltage Wiring Voltage Element (Phase to Square Code Config. Heater (Phase to Neutral) Inch Phase) 84401- 7000 7000 200 VAC 3 Wire 10.88 Blue 84401- 7000 7000 380 VAC 4 Wire 19.76 Yellow 84401-...
  • Page 53 Element Resistance Element Total Watts System Watt System Resistance Part Watt Color Voltage Wiring Voltage Element (Phase to Square Code Config. Heater (Phase to Neutral) Inch Phase) 84375- 14000 7000 230 VAC 3 Wire 14.4 Purple 84375- 14000 7000 240 VAC 3 Wire 15.68 Silver 7 7 .
  • Page 54 Using a 1/2 inch wrench, remove eight cap screws and two pivot blocks holding 4 4 ) ) faulty heater in place. NOTE: Carefully gather up any slack in the lead wires for the heaters in the adjoining vats at the back of the fryer to minimize the amount of disassembly of the pivot blocks and heaters to keep from disconnecting all the wires but allow the defective heater to be replaced.
  • Page 55 Tape new power leads to old lead left in place and route to controls area at front 5 5 ) ) of fryer and connect to contactor. Align pivot blocks and heaters straight across front of fryer and snug screws. 6 6 ) ) Lower elements into vats and adjust each so no elements rub sides of vat.
  • Page 56 7 7 . . 7 7 . . 2 2 R R e e p p l l a a c c e e m m e e n n t t Open left door. 1 1 ) ) Using a 9/16 inch wrench, remove retaining nut from below and remove breaker 2 2 ) ) from controls area.
  • Page 57 Form inside of control area, squeeze in on tabs on back of switch and push 2 2 ) ) switch out the front of control area. Label and remove wires from switch. 3 3 ) ) 7 7 . . 8 8 . . 1 1 C C h h e e c c k k o o u u t t Check across two sets of switch terminals for continuity.
  • Page 58 Disconnect 12-pin connector on left side of control panel. 2 2 ) ) Using multimeter, take ohm reading on appropriate oil temperature pins. If 3 3 ) ) readings are different than the following chart or control panel label, replace probe.
  • Page 59 T T a a b b l l e e 7 7 - - 3 3 R R T T D D R R e e s s i i s s t t a a n n c c e e C C h h a a r r t t Resist- Resist- Resistance...
  • Page 60 Go to front of fryer control panel for vat with suspect probe, loosed retaining 4 4 ) ) screw with Philip’s-head screwdriver and hinge control panel down. Disconnect 12-pin connector at left side of control panel and place connector on 5 5 ) ) flat surface with the open side up.
  • Page 61 Figure 7-1 Probe Assembly Install Push temperature probe through until it makes contact with gauge. 1 1 1 1 ) ) Tighten temperature probe in place. 1 1 2 2 ) ) E E x x c c e e s s s s f f o o r r c c e e w w i i l l l l d d a a m m a a g g e e t t e e m m p p e e r r a a t t u u r r e e p p r r o o b b e e .
  • Page 62 Note that left and right are as viewed from front of fryer. Also if any of the probes are out of calibration more than 10°F or 10°C, the probe should be replaced. An ohm check can be performed also. 7 7 . . 1 1 0 0 . . 1 1 C C h h e e c c k k o o u u t t O O i i l l L L e e v v e e l l P P r r o o b b e e S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , m m o o v v e e t t h h e e p p o o w w e e r r s s w w i i t t c c h h t t o o o o f f f f a a n n d d d d i i s s c c o o n n n n e e c c t t m m a a i i n n c c i i r r c c u u i i t t b b r r e e a a k k e e r r , , o o r r u u n n - -...
  • Page 63 Place connector on flat surface with the open side up. 7 7 ) ) Hold connector in place with one hand, use other hand to insert pocket knife 8 8 ) ) blade or other small sharp tool into connector notch to depress metal locking tab.
  • Page 64 Figure 7-2 Probe Assembly Install Push temperature probe through until it makes contact with gauge. 1 1 3 3 ) ) Tighten temperature probe in place. 1 1 4 4 ) ) E E x x c c e e s s s s f f o o r r c c e e w w i i l l l l d d a a m m a a g g e e t t e e m m p p e e r r a a t t u u r r e e p p r r o o b b e e .
  • Page 65 7 7 . . 1 1 1 1 E E l l e e m m e e n n t t S S e e n n s s e e S S w w i i t t c c h h This switch removes power to the element when the element is raised.
  • Page 66 Use Philip’s-head screwdriver and 5/16 inch nut driver to remove two screws 3 3 ) ) and nuts securing the switch. Reassemble with new switch, making sure switch lever is inside hole of element 4 4 ) ) sense arm and the switch is actuated, and then reconnect wires to the switch. Reinstall rear shroud.
  • Page 67 Figure 7-3 Contactors 7 7 . . 1 1 2 2 . . 1 1 C C h h e e c c k k o o u u t t Remove electrical power supplied to the fryer. 1 1 ) ) S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , m m o o v v e e t t h h e e p p o o w w e e r r s s w w i i t t c c h h t t o o o o f f f f a a n n d d d d i i s s c c o o n n n n e e c c t t m m a a i i n n c c i i r r c c u u i i t t b b r r e e a a k k e e r r , ,...
  • Page 68 Test Points Results From 30 to 34. open circuit. From 31 to 35. open circuit. From 32 to 36. open circuit. From 33 to 37 (coil). ohm reading 5 to 6. S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , m m a a k k e e c c o o n n n n e e c c t t i i o o n n s s b b e e f f o o r r e e a a p p - - p p l l y y i i n n g g p p o o w w e e r r , , t t a a k k e e r r e e a a d d i i n n g g , , a a n n d d r r e e - - m m o o v v e e p p o o w w e e r r b b e e f f o o r r e e r r e e m m o o v v i i n n g g m m e e t t e e r r...
  • Page 69 Using a 3/8 inch wrench or socket, remove two mounting nuts on base plate of 2 2 ) ) contactor begin replaced and remove contactor. When replacing the heat contactor, slide it from the mounting rail. 3 3 ) ) Install new contactor in reverse order.
  • Page 70 Using a 1/8 inch Allen wrench, remove four screws. 2 2 ) ) Pivot rear of motor down while lifting up to disengage motor sprocket from chain. 3 3 ) ) Disconnect motor lead wires at connector. 4 4 ) ) Install new motor assembly in the reverse order.
  • Page 71 7 7 . . 1 1 3 3 . . 2 2 S S w w i i t t c c h h e e s s R R e e p p l l a a c c e e m m e e n n t t S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , m m o o v v e e t t h h e e p p o o w w e e r r s s w w i i t t c c h h t t o o o o f f f f a a n n d d d d i i s s c c o o n n n n e e c c t t m m a a i i n n c c i i r r c c u u i i t t b b r r e e a a k k e e r r , , o o r r u u n n - -...
  • Page 72 Lightly push the switches bracket up against the adjustment head and hold in 4 4 ) ) place. Tighten mounting screws. Move lead wires from old switches to new switches. 5 5 ) ) D D r r i i v v e e c c h h a a i i n n a a n n d d s s p p r r o o c c k k e e t t s s w w i i l l l l b b e e g g i i n n o o p p e e r r a a t t i i n n g g .
  • Page 73 Using a 1 inch wrench, disconnect hard line from filter pump to elbow. 4 4 ) ) Using a 7/16 inch wrench, remove two mounting bolts from support at end of 5 5 ) ) valve. Using 1 7/16 inch wrench, remove two mounting bolts and two nuts and selector 6 6 ) ) valve assembly from fryer.
  • Page 74 Locate elbow and pipe plugs in ports of selector valve. Label corresponding 7 7 ) ) ports in new selector valve, and remove elbow and plugs from old valve and place into labeled ports in new valve. Assemble in reverse order. 8 8 ) ) 7 7 .
  • Page 75 Trace wires from P12 on panel to vertical wall of controls area and separate 2 2 ) ) required connector. Using a 7/32 inch Allen wrench, loosen and unscrew two set screw until almost 3 3 ) ) removed. Using a flat blade screwdriver, pry motor from valve body. 4 4 ) )
  • Page 76 Using a 1/4 inch or adjustable wrench, turn square stud shaft to operate valve 5 5 ) ) ball. Assemble in reverse order. 6 6 ) ) Support control panel bottom with one hand, swing panel top up about 90 7 7 ) ) degrees, let panel slide down slightly to clear screw, push panel top up to engage screw, then tighten screw.
  • Page 77 Trace wires from P12 on panel to vertical wall of controls area and separate 2 2 ) ) required connector. From the rear of the fryer and using a 3/8 inch wrench, remove two nuts 3 3 ) ) securing seal clamp to drain trough studs. Grasp drain valve and motor assembly, turn assembly 1/8 turn (45°) counter 4 4 ) ) clockwise (CCW) and slide assembly down so valve inlet clears vat drain tube.
  • Page 78 Reassemble in reverse order. Lubricate O-rings with cooking oil. Align “nubs” on 1 1 1 1 ) ) drain tubes with notches in valve body, push tube into valve body and turn 1/8 turn (45°) clockwise (CW) to lock position. 7 7 .
  • Page 79 To reassemble, place rotor on drive shaft, and place roller into rotor. 3 3 ) ) T T h h e e r r e e i i s s a a n n i i n n d d i i c c a a t t o o r r o o n n t t h h e e s s i i d d e e o o f f t t h h e e t t w w o o h h a a l l v v e e s s o o f f t t h h e e p p u u m m p p , , t t h h i i s s m m a a r r k k m m u u s s t t b b e e t t o o g g e e t t h h e e r r .
  • Page 80 Using crosshead screwdriver, remove the rear cover from motor, exposing the 5 5 ) ) wires. Loosen the conduit clamp, disconnect wires, and pull the wires through the 6 6 ) ) conduit clamp. Using 7/16 inch wrench, remove three nuts, lockwashers, flat washers, spacer 7 7 ) ) washer sets, and bolts securing the motor to the motor bracket.
  • Page 81 T T h h e e f f o o l l l l o o w w i i n n g g p p r r o o c c e e d d u u r r e e o o n n l l y y a a p p p p l l i i e e s s t t o o u u n n i i t t s s m m a a n n u u f f a a c c t t u u r r e e d d p p r r i i o o r r t t o o S S e e p p t t e e m m b b e e r r 2 2 0 0 1 1 8 8 .
  • Page 82 7 7 . . 1 1 6 6 J J I I B B P P u u m m p p This pump keeps the vats filled (Auto Top-Off) 7 7 . . 1 1 6 6 . . 1 1 R R e e p p l l a a c c e e m m e e n n t t S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , m m o o v v e e t t h h e e p p o o w w e e r r s s w w i i t t c c h h t t o o o o f f f f a a n n d d d d i i s s c c o o n n n n e e c c t t m m a a i i n n c c i i r r c c u u i i t t b b r r e e a a k k e e r r , , o o r r u u n n - -...
  • Page 83 Tag and pull connectors from AIF PC board located behind control panel. 2 2 ) ) Using a 5/16 inch socket, remove six nuts and board form fryer. 3 3 ) ) Install new PC board in reverse order. 4 4 ) ) 7 7 .
  • Page 84 S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , u u s s e e c c a a r r e e w w h h e e n n c c h h e e c c k k i i n n g g t t r r a a n n s s - - f f o o r r m m e e r r .
  • Page 85 Support control panel bottom with one hand, swing panel top up about 90 5 5 ) ) degrees, slide panel down slightly to clear screw, push panel up to engage screw, and tighten screw. 7 7 . . 2 2 0 0 C C h h e e c c k k V V a a l l v v e e A check valve is installed in the fill line to each vat to keep oil from flowing out of the vat.
  • Page 86 S S H H O O C C K K H H A A Z Z A A R R D D T T o o a a v v o o i i d d e e l l e e c c t t r r i i c c a a l l s s h h o o c c k k , , m m o o v v e e t t h h e e p p o o w w e e r r s s w w i i t t c c h h t t o o o o f f f f a a n n d d d d i i s s c c o o n n n n e e c c t t m m a a i i n n c c i i r r c c u u i i t t b b r r e e a a k k e e r r , , o o r r u u n n - - p p l l u u g g c c a a r r d d a a t t w w a a l l l l r r e e c c e e p p t t a a c c l l e e .
  • Page 87 Support control panel bottom with one hand, swing panel top up about 90 5 5 ) ) degrees, slide panel down slightly to clear screw, push panel top up to engage screw, then tighten screw. 7 7 . . 2 2 2 2 F F i i l l t t e e r r & & J J I I B B L L i i g g h h t t s s 7 7 .
  • Page 89 C C h h a a p p t t e e r r 8 W W i i r r i i n n g g D D i i a a g g r r a a m m s s The wiring diagrams are shown in this section.
  • Page 112 Figure 10-1 Plumbing Diagram...
  • Page 114 blank page...
