Secondary functions ( ):
In I/O grouping mode, selects group 1 (see
In I/O grouping mode, indicates that group 1 is selected.
configuration mode (see
Rate (Rear Panel)" on page 42).
Selects 9600 baud for the Remote RS232/RS422 and the RS-232 Config ports in
serial port configuration mode.
Indicates that the Remote RS232/RS422 and the RS-232 Config ports are set to
9600 baud in serial port configuration mode.
e
Preset button — The Preset button does the following:
Primary functions (❏):
❏
Places the switcher in preset saving mode to save a configuration as a preset, and
in preset recalling mode to activate a previously-defined preset.
❏
switcher is in preset recalling mode.
Secondary functions ( ):
In I/O grouping mode, selects group 2.
In I/O grouping mode, indicates that group 2 is selected.
configuration mode.
Selects 19200 baud for the Remote RS232/RS422 and the RS-232 Config ports in
serial port configuration mode.
Indicates that the Remote RS232/RS422 and the RS-232 Config ports are set to
19200 baud in serial port configuration mode.
f
<
View button
Primary functions (❏):
❏
Places the switcher in view-only mode to display the current configuration.
NOTE:
"Muting and Unmuting Video and Audio
❏
Indicates that the DXP is in view-only mode.
Secondary functions ( ):
In I/O grouping mode, selects group 3.
In I/O grouping mode, indicates that group 3 is selected.
configuration mode.
Selects 38400 baud for the Remote RS232/RS422 and the RS-232 Config ports in
serial port configuration mode.
Indicates that the Remote RS232/RS422 and the RS-232 Config ports are set to
38400 baud in serial port configuration mode.
"I/O Grouping" on page 28).
< >
buttons, places the switcher in serial port
"Selecting the RS-232/RS-422 Protocol and Baud
>
<
buttons, places the switcher in serial port
<
button does the following:
>
buttons, places the switcher in serial port
Outputs" on page 34).
15
