Audio breakaway — An embedded audio signal can be separated from its
corresponding video signal within the switcher, allowing the audio and video signals
from one source to be switched to different destinations
32 global presets — Frequently used I/O configurations can be saved and recalled
as global presets either from the front panel, IP Link, or serial control. This allows I/O
configurations to be set up and stored in memory for future use.
I/O mode viewing
connected.
QuickSwitch Front Panel Controller (QS-FPC) — The DXP front panels provide a
discrete button for each input and output.
Tri-color back-lit buttons — The front panel buttons illuminate red, green, or amber,
depending on function, for ease of use in low-light environments, and can be custom
labeled for easy identification.
IP Link Ethernet control — The DXP matrix switchers can be monitored and
status.
RS-232 and RS-422 control
Remote RS232/RS422 port or the front panel 2.5 mm TRS Config port, you can
control and configure the DXP switchers via the included Matrix Switchers Control
Program, or integrate the switchers into a control system. Firmware updates can also
be installed via this port.
Simple Instruction Set (SIS ™ ) commands
ASCII code commands that easy programming through a control system via an RS-232
or RS-422 connection.
Control software
computer, the Matrix Switchers Control Program is provided with the DXP switcher.
This icon-driven software uses a graphical, drag-and-drop interface to provide easy I/O
configuration and other customization. The control software also offers an emulation
mode for configuration of an offsite switcher; the configuration can then be saved for
future downloading to the switcher.
Optional remote control — Available as an option is the MKP 2000 or MKP 3000
RS232/RS422 port, providing the flexibility to control a DXP matrix switcher from a
remote location.
Front panel security lockout — Front panel lockout (executive mode) prevents
unauthorized use in non-secure environments. In lockout mode, a special button
combination is required to unlock operation of the switcher from the front panel.
Rack-mountable 2U, full rack width metal enclosure
Internal universal power supply
power supply provides worldwide power compatibility.
High-bandwidth Digital Content Protection (HDCP) compliance — The DXP
enables simultaneous distribution of a single source signal to one or more displays.
protection of digital television broadcasts and high resolution digital video output from
3
