COMPRESSED AIR CONNECTION FOR ADDITIONAL SEALING PRESSURE
• Additional sealing pressure is usually recommended for MAP applications only.
• The M40-M80 and the L10-L60 models with the option Gas/MAP are standard equipped with a compressed
air inlet.
• Extra sealing pressure is not necessary and not available for the Table-Top, M10, M20, M30.
• Consult your dealer for installation details.
• Maximum pressure: 1 bar.
• Assure a good connection and use high-quality connector.
DIGITAL CONTROL WITH LCD DISPLAY
Some Henkovac vacuum machines have a control system with just one Program (P1). Other machines have
an optional expanded control system, which can accommodate up to 9 custom programs (P1-9).
ONE-PROGRAM CONTROL SYSTEM
Henkovac machines with the One-Program control system can be programmed for the following 2 functions:
1. Vacuum time (seconds).
2. Sealing time (seconds).
• The values for vacuum and sealing times are selected by the user and saved in program P1.
• During operation, the LCD display will show symbols to indicate the active function and the progress of the
packing cycle.
• The actual vacuum pressure is indicated by the analog vacuum gauge.
PLUG AND PLAY
• When turning on the machine for the first time:
- Running time of the vacuum pump is pre-set at 30-40 seconds and the sealing time at 2 seconds.
Vacuum is indicated on the analog vacuum gauge.
• When turning on the machine after that, program P1 will contain the most-recently used settings.
• The vacuum and sealing times are easily adjusted to match the needs for the application.
