Never operate the machine when the oil level is low. It is recommended to change the oil at least every
2 months.
TURNING ON MACHINE
• If so equipped, like some mobile and double-chamber models, turn on the main power switch on the back
of the machine.
• Push the on/off button on the control panel of the machine.
gAS CONNeCTION fOr mAP APPLICATIONS (mOdIfIed ATmOSPherIC
PACkAgINg)
• Connect the gas supply line to the inlet on the back of the machine.
• Maximum pressure: 1 bar.
• Anchor the gas cylinders securely to prevent them from falling over.
• Make sure that the work area is well-ventilated.
• To assure that you use the appropriate gas for your application, consult your dealer or gas supplier.
• Assure a good connection and use high-quality materials.
COMPRESSED AIR CONNECTION FOR ADDITIONAL SEALING PRESSURE
• Additional sealing pressure is usually recommended for MAP applications only.
• The M40-M80 and the L10-L60 models with the option gas/MAP are standard equipped with a compressed
air inlet.
• Extra sealing pressure is not necessary and not available for the Table-Top, M10, M20, M30.
• Consult your dealer for installation details.
• Maximum pressure: 1 bar.
• Assure a good connection and use high-quality connector.
DIGITAL CONTROL WITH LCD DISPLAY
Some Henkovac vacuum machines have a control system with just one program (P1). Other machines have
an optional expanded control system, which can accommodate up to 9 custom programs (P1-9).
ONE-PROGRAM CONTROL SYSTEM
Henkovac machines with the one-program control system can be programmed for the following 2 functions:
1. Vacuum time (seconds).
2. Sealing time (seconds).
• The values for vacuum and sealing times are selected by the user and saved in program P1.
• During operation, the LCD display will show symbols to indicate the active function and the progress of the
7
