Parts Breakdown
Model VP-NL-0050-SN
Item No. Description
65704 Din-Rail 380mm for 59014
Combi-Trafo P200/460V-S24/32V for
15792
59014
65705 Wartel M16x1.5 KS for 59014
65706 Moer M16x1.5 KS for 59014
65707 Moer M20x1.5 KS for 59014
35376 Cable Gland M20x1.5 Plastic for 59014
35305 End Fent for 59014
35315 Double Clamp 2.5-2 for 59014
65708 Sluitplatt Zap ZDU 6-2 for 59014
35323 Endplate Wireconnector for 59014
Item No. Description
65753 Cap Wide Holder 04-Control for 59014
65754 Cover Protection 04-Control for 59014
59014
Position Item No. Description
1 15771 Closed Contactor 24VAC for 59014
2 35687 Wire Clamp 2.5-2/2 AN for 59014
3 35688 Clamp Connector 2.5/2 for 59014
Zekering Keram.5x20 2.5A Traag for
4 35307
59014
5 35555 Cover Switchbox for 59014
6 35306 Fuse Clamp 2.5-2/ZSI for 59014
Hexagon Flangenut M5 DIN6923 A2
7 27782
for 59014
Micro Cellular Rubber 4mm Black for
8 35559
59014
Montageplaat 2.5mm2 04-Series for
9 65709
59014
Hexagon Flangenut M4 DIN6923-A2
10 35141
for 59014
Position Item No. Description
Grommet 16mm (283 1600 599 99) for
3 65755
59014
Grommet 20mm (283 1600 599 99) for
4 65756
59014
Position Item No.
11 65710
12 35318
13 35317
14 65711
15 65712
16 65713
17 65714
18 35304
19 15772
20
Position Item No.
5 65740
6 AI920
50
Switch Box
Description Position
Embr AB193-ED1*P for 59014 21
Wireclamp 6-2/2 AN for 59014 22
Earth Terminal PE 6-10 for 59014 23
Sluitplaat Pap PDU 6/10 for 59014 24
Doorverbinder ZQV 6/2 for 59014 25
Wartel M12x1.5 KS for 59014 26
Moer M12x1.5 KS for 59014 27
Earth Terminal PE 4-2/3 for 59014 28
Contactor 24VAC for 59014 29
Control Panel
Description Position
Cap Small Holder 04-Control for 59014 7
Houder Groot - PCB-HV Sensor for
9
59014
