- Page 1 Vacuum Packaging Machine Model VP-CN-0600 Item 43632 Instruction Manual Revised - 06/16/2022 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model VP-CN-0600 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 5 Installation --------------------------------------------------------------------------------------- 5 - 6 Operation ----------------------------------------------------------------------------------------- 7 - 8 Maintenance ----------------------------------------------------------------------------------- 8 - 10 Troubleshooting... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. -
Page 5: Technical Specifications
Safety and Warranty Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally. Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not improper use. Please see https://omcan.com/disclaimer for complete info. -
Page 6: Installation
Installation precautions. • You must fill the vacuum pump with NO.68 or NO.100 vacuum pump oil before use. When running, the oil level should not be lower than 1/3 height of oil window. Do not fill beyond the 1/2 mark. •... -
Page 7: Operation
• Mind your head when the lid opens, avoid the lid striking your head. • Please ask Omcan when requiring troubleshooting, do not attempt repairs by yourself. IMPORTANT INFORMATION ABOUT COOLING: THE COOLING TIME MUST BE SET AT LEAST 1... -
Page 8: Maintenance
Operation SECOND LONGER THAN THE SEALING TIME, FAILURE TO DO SO MAY RESULT IN A FIRE. Maintenance FILLING THE OIL Remove the cover board and unscrew the bottom nut from the oil tank to drain the old oil. Once drained, reconnect the nut and unscrew the top nut of the oil tank, fill with new food grade oil and reattach the screw. - Page 9 Maintenance 4. Remove the forcing screws from the two sides of the sealing bar with an Allen Key, then remove the heating wire. 5. Put one side of a new heating wire into the fastener groove and tighten it with the Allen Key. 6.
- Page 10 Maintenance 8. Take the new sealing tape at a proper length and stick it on the heating wire. 9. Cut the remaining sealing tape on the ends to allow them to fold over. 10. Put plastic clamps on the sides of the sealing bar. 11.
-
Page 11: Troubleshooting
Troubleshooting VACUUM PUMP AND VACUUM SYSTEM Vacuum pump does not start, the possible reasons are as follows: • Limit switch is not pressed on: - Close the machine cover and adjust the limit switch. - Adjust the pull-rod for electric cover opening machine. •... -
Page 12: Parts Breakdown
Sealing can’t be pressed tightly caused by insufficient bulge of gas bag. • Air bubble shrinks caused by insufficient cooling time. • Heating sealing bar is damaged and the surface is not flat. Parts Breakdown Model VP-CN-0600 43632 Item No. Description Position Item No. - Page 13 Parts Breakdown Model VP-CN-0600 43632...
-
Page 14: Electrical Schematics
Electrical Schematics Model VP-CN-0600 43632... -
Page 15: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 16 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
