Technical Specifications

Model
Seal Length
Vacuum Pump
10 Programmable
Control
Maximum Product
Height
Useful Chamber Size
Power Consumption
Electrical
Weight
Dimensions
Item Number
Installation
GENERAL
• Level the machine on a flat firm surface.
• Position the machine in such a manner that the pump is unobstructed and properly ventilated.
• Engage the locks on the wheels, if so equipped.
• Check the oil level in the pump; add oil if necessary.
Never operate the machine when the oil level is low. It is recommended to change the oil at least every
2 months.
TURNING ON MACHINE
• If so equipped, like some mobile and double-chamber models, turn on the main power switch on the back
of the machine.
• Push the on/off button on the control panel of the machine.
GAS CONNECTION FOR MAP APPLICATIONS (MODIFIED ATMOSPHERIC
PACKAGING)
• Connect the gas supply line to the inlet on the back of the machine.
• Maximum pressure: 1 bar.
• Anchor the gas cylinders securely to prevent them from falling over.
• Make sure that the work area is well-ventilated.
• To assure that you use the appropriate gas for your application, consult your dealer or gas supplier.
• Assure a good connection and use high-quality materials.
VP-NL-3016-SN VP-NL-3008-SN
12.6" / 320mm
16 m³
No
6.3" / 160mm
13" x 12.6" x 6.3"
330 x 320 x 160mm
0.7 kW
110V / 60Hz / 1 115V / 60Hz / 1
110.2 lbs. / 50 kgs.
21.6" x 17" x 16.14"
549 x 432 x 410mm
59011
VP-NL-0040-SN
16.5" / 420mm
8 m³
Yes
7" / 180mm
14.6" x 16.5" x 7"
370 x 420 x 178mm
0.7 - 1.3 kW
110V / 60Hz / 1
132 lbs. / 60 kgs.
21.9" x 20.7" x 18.1"
555 x 525 x 460mm
59012 59013
6
VP-NL-0050-SN
12.6" / 320mm
21 m³
No
3.9" / 100mm
12.6" x 31.5" x 3.7"
320 x 800 x 94mm
1.3 kW
120V / 60Hz / 1
253.5 lbs. / 115 kgs.
20.3" x 39" x 17"
516 x 991 x 432mm
59014
