Omcan VP-NL-3016-SN Instruction Manual page 48

Parts Breakdown
Model VP-NL-0050-SN
Item No. Description
65864 Omkasting T5 for 59014
AI921 21m3 Vacuum Pump for 59014
65865 Bodemplaat T5 for 59014
Control Panel Small-PCB 1-Program
AI879
for 59014
Vibration Absorber D=25 H=17 M6x10
65834
for 59014
62719 Switchbox Model-I SC-DC for 59014
Valve 2/2 MA-222-003-P27-SAH 24
35285
for 59014
Brass Hose Coupling 1/8x6 Ext. for
35207
59014
65842 Sealbalk DS-3-320 for 59014
65868 Inlegplaat M3/T5-KK for 59014
65869 Achterwand T5 for 59014
Item No. Description
AI922 Vacuumbak T5 / S50 for 59014
AI923 Blindstop 1/8" Bu Zesk MS-VN for 59014
Sealing Washer 0251796/0251797 for
35431
59014
35202 Gasnozzle STST 1/8 for 59014
Slotted Cheese Head Screw M4x6 A2
27830
DIN84 for 59014
65775 Sealsnoer C1 for 59014
65776 Spring Washer DIN 127 - A4 for 59014
Spring Ring with Cover 6mm / Shaft
27810
Locker with Cover for 59014
AI888 Scharnieras T3 for 59014
27823 Hexagon Nut M3 DIN934 A2 for 59014
59014
Position Item No. Description
1 65870 Dekselsluiting E-163 for 59014
Elma Afdekknop 040-3020 Zwart for
2 65846
59014
3 27824 Castle Washer M6 for 59014
M6x16 Cylinder Head Cap Screw DIN
11 65792
912 for 59014
Hucknagel Magna-Lok MGLP-B6-4 for
16 65836
59014
18 35219 Flat Washer M8 D9021 A2 for 59014
Hexagon Screw M8x10 DIN933 A2 for
26 35220
59014
M8x45 Hexagon Socket Set Screw DIN
27 65750
916 for 59014
33 65751 M8 Hexagon Cap Nut DIN 917 for 59014
Hexagon Screw M6x12 DIN933 A2 for
52 30005
59014
53 65749 M6 Hex Nut Din 985 for 59014
Position Item No. Description
1 65772 M3 Washer DIN 9021 for 59014
M3x16 Cross Recessed Raised Cheese
2 AI850
Head Screws - DIN 7985 for 59014
3 AI846 M5 Hexagon Cap Nut DIN 917 for 59014
4 15775 Micro Switch MV3003L for 59014
Adj.Screw/Soc.Head M6x25 DIN916 A2
5 27788
for 59014
6 27837 Hose (O2) Drago 6x13 for 59014
7 62740 Vacuum Valve D4 for 59014
T5/M3 Scharnierdeel Geassembleerd
8 AI924
for 59014
9 65765 Verlengstuk Sealcilinder 27mm for 59014
10 30017 Y Connecting Piece 6mm for 59014
Position Item No.
54 27789
56 27796
57 27794
58 35224
59 27795
60 35223
61 65748
62 27835
63 15832
64 65740
65
Position Item No.
11 27381
12 27832
13 65774
14 65764
15 27799
16 30019
17 30010
18 35201
19
20
48
Overall
Description
Slott.Rais.Counter.Head Screw M4x10
DIN7985 A2 for 59014
Sticker Oil for 59014
Sticker Machinetype for 59014
Sticker 98x65 Yellow for 59014
Sticker Tension Triangle for 59014
Sticker 19x38 Yellow for 59014
Slangpilaar G1-2x19mm BU for 59014
Hose Clip ABA 15-24mm for 59014
PVC Suctionhose HNA-20x3.4mm for
59014
Cap Small Holder 04-Control for 59014
Vacuum Chamber
Description
O-Ring 34x3mm for 59014
O-Ring 40x3mm for 59014
Distance Ring 8mm for Seal Cilinder
90mm for 59014
Sealcylinder 90mm Trough Shaft
Assemb. for 59014
Plastic Nut M24 for 59014
Hose Clip Klemfa 12.8x14.8mm for
59014
Brass Nut 1/4 for 59014
Elbow Brass for Gaspipe for 59014
Position
66
67
68
69
70
71
72
73
74
75
Position
21
22
23
24
25
26
27
28
