Vacuum Packaging Machine
Model VP-NL-0050-LS
Item 45310
Instruction Manual
Revised - 02/28/2023
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-NL-0050-LS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omcan VP-NL-0050-LS

Summary of Contents for Omcan VP-NL-0050-LS

  • Page 1 Vacuum Packaging Machine Model VP-NL-0050-LS Item 45310 Instruction Manual Revised - 02/28/2023 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...

  • Page 2: Table Of Contents

    Table of Contents Model VP-NL-0050-LS Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 7 Operation --------------------------------------------------------------------------------------- 7 - 11 Maintenance --------------------------------------------------------------------------------- 11 - 15 Troubleshooting...

  • Page 3: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 4: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 5 1 YEAR PARTS AND LABOR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule Omcan authorized service technician to repair the equipment locally.

  • Page 6: Technical Specifications

    Technical Specifications Model VP-NL-0050-LS Seal Double 29.3” | 31.7” | 32.3” Seal Length 745mm | 805mm | 820mm Description Stainless Steel Cover - Flat Working Surface Electrical 220V / 50Hz / 3 Digital Time Control 10 Programs Pump Capacity 63 m3/h Dimensions 37”...

  • Page 7: Installation

    Installation COMPRESSED AIR CONNECTION FOR ADDITIONAL SEALING PRESSURE • Additional sealing pressure is usually recommended for MAP applications only. • The M40-M80 models with the option Gas/MAP are standard equipped with a compressed air inlet. • Consult your dealer for installation details. •...

  • Page 8: Operation

    Operation Menu Button: • Toggles between Home menu and Settings menu • Save Function: During programming, confirms and saves the entered program values and returns to the Home menu. • Return Function: Returns to the Home menu. review program values: •...
  • Page 9 Operation When turning off the machine with the button, the symbol will start blinking on the LCD display: • The pump will stop after about 4 seconds. • Press the button for a second time and the pump will stop immediately. •...
  • Page 10 Operation REVIEWING FUNCTION VALUES FOR P1-P9 1. Turn the machine on by pushing the button. 2. The most-recently used program will be indicated. 3. All selected functions for this program are indicated at the bottom of the display. 4. To review the values for these functions, push the button;...

  • Page 11: Maintenance

    Operation 5. Close the cover and the machine will initiate the cool-down phase and perform a number of vacuum cycles while the cover stays closed and the machine will turn off automatically after about 15 minutes. - These cycles are necessary to cool down the machine and to allow any moisture in the oil of the pump to evaporate.
  • Page 12 Maintenance ADDING AND CHANGING THE PUMP OIL WARNING The operating temperature of the pump is 70° C / 158° F or higher. Wear gloves when servicing the pump or let it cool off sufficiently to prevent injuries. ADDING OIL 1. Remove the oil filler cap 2.
  • Page 13 Maintenance NOTES • Check the condition of the tensioning springs at both ends of the seal beam; replace if necessary. • These springs maintain tension on the sealing wire. • Using the seal beam without the springs may cause sealing wires to break. INSTALL THE SEALING WIRE AND TEFLON TAPE AS FOLLOWS: 1.
  • Page 14 Maintenance 5. Apply the Teflon tape smooth and tight over the seal beam without creases. Make sure that the beam is clean and free of grease. 6. Re-install the seal beam in the vacuum chamber and re-connect the wires. ALUMINUM T-SHAPED SEAL BEAM REMOVE THE SEALING WIRES AS FOLLOWS: 1.

  • Page 15: Troubleshooting

    Maintenance RUBBER SEAL OF VACUUM CHAMBER COVER To assure that the vacuum chamber is properly sealed, it is important that the rubber seal is in good condition and is not damaged. Replace the cover seal as follows: 1. Copy the length of the original rubber seal. 2.
  • Page 16 Troubleshooting The vacuum in the package is The programmed vacuum value is Lower the vacuum value in the insufficient. too high. program. The packaging material is of poor Select a better-quality packaging quality. material. The product damages the bag. Program a higher value for Soft- Air.

  • Page 17: Parts Breakdown

    Parts Breakdown Model VP-NL-0050-LS Vacuum Pump 45310...
  • Page 18 Parts Breakdown Model VP-NL-0050-LS Worktable 45310...
  • Page 19 Parts Breakdown Model VP-NL-0050-LS 45310...
  • Page 20 Parts Breakdown Model VP-NL-0050-LS Seal Bar 45310...
  • Page 21 Parts Breakdown Model VP-NL-0050-LS Vacuum Valve 45310...
  • Page 22 Parts Breakdown Model VP-NL-0050-LS Switch Box 45310...
  • Page 23 Parts Breakdown Model VP-NL-0050-LS Control Panel 45310...
  • Page 24 Parts Breakdown Model VP-NL-0050-LS Vacuum Pump 45310 Item No. Description Position Item No. Description Position Item No. Description Position Hexagon Flangenut M5 Din6923 A2 AM518 Chassis M5 for 45310 AM522 Cover Backside M5 for 45310 27782 for 45310 Hexagon Flangenut M6 DIN6923 A2 65822 Lid M5-S&S for 45310...
  • Page 25 Parts Breakdown Model VP-NL-0050-LS Worktable 45310 Item No. Description Position Item No. Description Position Item No. Description Position AM525 Worktable M5-KK for 45310 AM529 Knee 1/2 90 F-F AISI 316 for 45310 AM539 Support Hinge Block MB for 45310 Adj.Screw/Soc.Head M6x25 DIN916 A2 35821 Spacer Sil.Holder Gas 6mm for 45310...
  • Page 26 Parts Breakdown Model VP-NL-0050-LS 45310 Item No. Description Position Item No. Description Position Item No. Description Position Hexagon Screw M10x25 DIN933 A2 AM545 Seal for Lid HD for 45310 35941 AM548 V-Ring Type V-050-A for 45310 for 45310 Hex.Socket Head Cap Screw M5x25...
  • Page 27 Parts Breakdown Model VP-NL-0050-LS Switch Box 45310 Item No. Description Position Item No. Description Position Item No. Description Position 65704 Din-Rail 380mm for 45310 15771 Closed Contactor 24VAC for 45310 65710 EMBR AB193-ED1*P for 45310 Combi-Trafo P200/460V-S24/32V for 15792 35687 Wire Clamp 2.5-2/2...

  • Page 28: Electrical Schematics

    Electrical Schematics Model VP-NL-0050-LS 45310...

  • Page 29: Notes
