WisyCom MCR42 User Manual page 33

H W
OW TO USE
Wisycom MCR4x Manager can be used to:

Change the name of the receivers RX1 and RX2

Change the name of the Presets

Change name and description of the groups

Assign a name and an Expander to a single channel

Modify/load/save the channels memory

Upgrade firmware
Instruction to connect MCR4x and UPK300E/UPK Mini:
Connect to the PC the infrared programming interface (UPK300E/UPK Mini) using a USB
1.
cable (it is not possible to use IR interface of MRK950 or MRK960)
NOTE: the USB drivers must be installed on the PC, for further info check on the
Download area of the Programmers (UPKxx) on Wisycom website.
2. Check if the version of Wisycom Manager in your PC is the latest version otherwise
download the latest version from Wisycom website
(http://www.wisycom.com/www3/products/product/mcr42#4
3. Run Wisycom Manager and then Wisycom MCR4x Manager
4. Power up the receiver MCR41/42 and enable the IRDA interface:
a. push
b. push
on>Edit RX1>Edit RX2>LINE mode>Display>Infrared)
c. push again
Put in front the IRDA interface of MCR41/42 to the UPK300E/UPK Mini
5.
MCR4
ISYCOM
button,
button until that Infrared submenu appears on the display (Power
button and check the display shows 'IR IF active'
MCR41/MCR42 User Manual
M
X ANAGER
( . 1.0.2
V
)
OR ABOVE
).
