TOP FEED COMPATIBILITY
MCR42/41- BPA42-PTT
EL2 X
ELC X
ECL X
EC2 X
X: for all firmware versions
Y: only for firmware versions > 1.0.75 (Factory preset)
CABLES
27
UFLA42-IK-OP
CAU42-IKSS
CAP51-IK
CAP52-IK
BPA42-HPN SLK42-IK
X X
Y
Y
Y
CAM50-2 /
CAM120-2
CAM50-3
CAM50-41
Ikegami flange compatible with new PSC Six Pack
STAND ALONE HARNESS CABLE- DB25
(to MCR42,Ikegami/Panasonic slot-in compatible)- 2
XLR-3M (line output) + USB (power and management
with SLK42-IKSS/2)
STAND ALONE HARNESS CABLE- DB25
(to MCR41, Ikegami/Panasonic slot-in compatible)- 1
XLR-3M (line output isolated with audio tranformer) +
hirose (to camera)
STAND ALONE HARNESS CABLE- DB25
(to MCR42,Ikegami/Panasonic slot-in compatible)- 2
XLR-3M (line output isolated with audio tranformer) +
hirose (power from camera)
SLK42-IK-PSC
X
Y
Y
Y
AF cable (50 / 120 cm), mini XLR-3F / XLR-3M
connectors
AF cable (50 cm), mini XLR-5F / 2 XLR-3M
connectors
AF cable (50 cm), mini XLR-5F / 1 XLR-3M
connectors
Line 1 feed XL3-M (TO BE USED FOR AES3 CAMERA
INPUT)
SLK42-PH SLK42-SX
X X
Y Y
Y Y
Y Y
