Chapter 8
AI
Coupon Extended Code – Number System Character
8102
Mutually Agreed, Between Trading Partners or FACT
90
91
92
93
94
95
96
97
98
99
Each subfield's format is expressed as the format of the Application Identifier number + the
format of the associated data. Each subfield must adhere to the format specified or else the
printer will be unable to locate following subfields, causing errors generating the bar code.
Any variable length subfield, unless it is the last subfield in the field, must be terminated by
the two characters "#6" (pound+6). These characters are translated as the Code 128
"FNC1" character, which is specified by the UCC/EAN 128 symbologies variable-length field
terminator. The characters "#6" are only used internally and are not printed.
Several Application Identifiers (00, 01, 22, and 8003) specify fields that will have a check
digit as part of their data. A character must be included in the check digit place (although it
need not be the correct check digit). This character is used as a placeholder and will not be
printed. The printer will calculate the correct check digit and replace the character already
there.
8.1.23 UCC/EAN Text Information, TCI 51
The TCI 51 generates the UCC/EAN information as text. This TCI uses the same criteria for
formatting as the TCI 50 bar code. The CGN selects the desired resident font that will be
used to generate this string. The printer will automatically surround each application
identifier with parentheses and add a space character in front of the data when using a TCI
of 51. Do not use the parentheses or spaces when entering the data for an application
identifier field.
438 Operator's Manual - 880052-0103
Content
preceded by zero
Dis
Intra-Company (Internal)
Intra-Company (Internal)
Intra-Company (Internal)
Intra-Company (Internal)
Internal-Carriers
Internal-Carriers
Intra-Company (Internal)
Intra-Company (Internal)
Internal
Table 8-8

UCC/EAN Application Identifiers

Bar Codes
Format
n4+n1+n1
n2+an..30
n2+an..30
n2+an..30
n2+an..30
n2+an..30
n2+an..30
n2+an..30
n2+an..30
n2+an..30
n2+an..30
8-23
