Microcom 438 Operator's Manual page 14

Chapter 1:
1.1 General Specifications
Width*
Height*
Depth*
Weight*
Electrical
Current
Temperature
Humidity
SRAM Memory
Code Flash Memory
User Flash Memory
Agency Approvals
Interface Communications
Flow Control
Baud Rate
Parity
Data Bits
Protocols
* NOTE: Listed specifications are based on a standard print mechanism and may vary
1.2 Printing Specifications
Print Type
Print Resolution
Maximum Print Speed
Maximum Print Width
Maximum Print Length
438 Operator's Manual - 880052-0103
Printer Specifications
8.5" (216 mm)
6.9" (175 mm)
4.8" (122 mm)
7.8 lbs. (3.5 kg)
Voltage: Auto-sensing; 100–240 VAC; 50–60 Hz
4 Amps maximum
40 – 104° F (5 – 40° C), operating
10 – 85%, non-condensing
512 K
512 K
8 MB
RoHS, FCC Class A, cTUVus
RS-232 (9 pin D-Sub connector (DCE)), USB (version
1.1 supported), and optional 10/100BASE-T Ethernet
CTS/RTS Hardware
110 to 115200
Odd, Even, and None
7 or 8
TCP/IP
based on final configuration.
Table 1-1 General Specifications
Direct Thermal
203 DPI (8 dots/mm = 0.0049" per dot)
300 DPI (12 dots/mm = 0.0032" per dot)
8"/sec. (203 mm/sec.)
438 - 203DPI = 4.098" (104 mm)
50" (1,270 mm) with 203 dpi
Table 1-2 Printing Specifications
438*
1-1
