Getting Started
3.3.12.1 Presenter tab - Configuration
The fields listed under the Configuration section control the Presenter operation on printer
model that are compatible with the presenter.
3.3.12.2 Configuration - Modes
This is used to select the mode of the presenter. The valid modes are enabled,
passthrough, and disabled. When selecting Enabled, the printer with presenter would
present the media using the other fields for operation while selecting Passthrough mode will
simply cause the presenter to run while the printer is printing.
3.3.12.2.1 Configuration - Take-Label/Retract Timeout (secs)
This field controls the time that the presenter will present the paper before retracting into the
waste bin.
3.3.12.2.2 Configuration - Maximum Present Distance (inch)
This is the maximum size that the printer will present when using the enabled mode. This
value is in inches.
3.3.12.2.3 Configuration - Loop Height (1/10 inch)
The Loop Height is a value in 1/10 inch that the printer uses to delay the presentation of the
media. The printer would print and form a loop at the presenter and once this value is
reached, the presenter would present.
3.3.12.3 Configuration - Advanced
The Advanced button is included as a manual override of the recommended settings that
the presenter will use for the various speeds. Typically, these values do not need to be
adjusted for the presenter to function.
3.3.13 Printing Preferences - Modification tab
This tab is used to control the number of copies, print speed, and port monitor status
enable.
3.3.13.1 Modification - No of Labels
This field controls how many copies of the current page will be printed.
