Chapter 8
NOTE: MULTIPLYING THE BARCODE GENERATED.
The barcode generated is based on a single dot width. For the barcode to be visible and to
scan properly, a reasonable multiplier must be used. Typical values for a multiplier are 8-
10. This is accomplished in the LDS1 format above on the line: 1,300,300,1,52,,,,10,10
Size - 0
This parameter is used to set the size the QR code to be generated. A value of "0" will
generate an automatically scaled QR code. The overall size of the barcode is controlled by
the Size and by the formats X and Y multiplier values.
438 Operator's Manual - 880052-0103
Size Value
0 Auto
1 21x21
2 25x25
3 29x29
4 33x33
5 37x37
6 41x41
7 45x45
8 49x49
9 53x53
10 57x57
11 61x61
12 65x65
13 69x69
14 73x73
15 77x77
16 81x81
17 85x85
18 89x89
19 93x93
20 97x97
21 101x101
22 105x105
23 109x109
24 113x113
25 117x117
26 121x121
27 125x125
28 129x129
29 133x133
30 137x137
31 141x141
0 Auto
1 21x21
Table 8-12

QR Size Values

Bar Codes
8-27
