Sensor Status Byte Definitions - Microcom 438 Operator's Manual

Chapter 5
4
5
6
7
8
X 178 Pre-takeup Delay: This command is used in conjunction with the Takeup
feature of the printer and requires that takeup code is installed in the PIC and
is also enabled by the ^D26 command. The command delays the start of the
takeup motor by the X value in steps after the main motor starts. The valid
range is 0 to 65535 steps. Please note that if a value is selected that exceeds
to format LSY, the takeup would not turn on.
438 Operator's Manual - 880052-0103
Input 2
Input 1
LTS / TOF
Transmissive
Registration Sensor
Reflective
Registration Sensor
Table 5-5

Sensor Status Byte Definitions

Printer Commands
See Sw3-4 (D23)
See SW3-2 (D23)
1 = Stock Detected
0 = No Stock Detected
1 = No Stock Detected
0 = Stock Detected
1 = No Stock Detected
0 = Stock Detected
5-47
