Sensor Status Byte Definitions - Microcom 224 Operator's Manual

Printer Commands
Bit Position
(12345678)
1
2
3
4
5
6
7
8
5-54
Definition
Reserved
Reserved
PSO (Pre Stock Out)
Input 2
Input 1
LTS / TOF
Transmissive
Registration Sensor
Reflective
Registration Sensor
Table 5-7

Sensor Status Byte Definitions

Operation
NA
NA
1 = Stock Detected
0 = No Stock Detected
See Sw3-4 (D23)
See SW3-2 (D23)
1 = Stock Detected
0 = No Stock Detected
1 = No Stock Detected
0 = Stock Detected
1 = No Stock Detected
0 = Stock Detected
