UT-4500 Series C- and Ku-Band Up Converters
Serial Interface Operation
8.7.5.3

RUS (Utility Status)

Description Details
Utility Status: <DEV/RUS_{cr}
Confirmation: >DEV/RUS_{cr}
COMM_aaaaaa{cr}
ADD_xxx{cr}
BR_nnnn{cr}
FMT_x-y-z{cr}
REF_xxx{cr}
SLP_x.x{cr}
CON_xx{cr}
LCD_xx{cr}{lf}]
8.7.5.4

RAS (Alarm Status)

Description Details
Alarm Status: <DEV/RAS_{cr}
Confirmation: >DEV/RAS_{cr} where:
xx = OK or FT
P15_xx{cr}
P14_xx{cr}
VCC_xx{cr}
5VD_xx{cr}
TEM_xx{cr}
IFL_xx{cr}
SUM_xx{cr}
COR_xx{cr}
FIN_xx{cr}
HSB_xx{cr}
REF_xx{cr}{lf}]
The unit returns REF_xx only when an external reference is present.
8.7.5.5

SAS (Summary Alarm Status)

Summary alarm is set to Fault (FT) if any of the RAS Alarm Status items (Sect.
8.7.4.4) are faulted.
Description
Summary Alarm:
Confirmation:
RS-232 or RS-485
Address (001 to 255)
Baud Rate (1200, 2400, 4800, 9600, 19K2, or 38K4)
Data Format x=data, y=parity, z=stop bit (8-N-1, 7-E-2, 7-O-2)
Osc. Adjust (000 to 255)
Slope Adjust (0.0 to 1.0)
LCD Contrast (0 to 30)
LCD Brightness (0 to 30).
15V DC Fault
14V DC Fault
VCC Fault
5VD Fault
Temperature Fault
IFLO Lock Fault
Sum Lock Fault
Coarse Lock Fault
Fine lock Fault
High Speed Bus Fault
Ref. Lock Fault (See Note)
Details
<DEV/SAS_{cr}
>DEV/SAS_xx{cr}{lf}] where:
xx = OK or FT
