UT-4500 Series C- and Ku-Band Up Converters
Serial Interface Operation
8.7.5.10

PACRUS (Packed Utility Status)

Description
Utility Status:
Confirmation:
Details
<DEV/PACRUS_{cr}
>DEV/PACRUS_ abbcdeeffghhii{cr}{lf}] where:
a = 0 (RS-232) or 1 (RS-485)
bb = Address in hex (01 to FF)
c = 0 if Baud Rate 38400
= 1 if Baud rate 19200
= 2 if Baud rate 9600
= 3 if Baud rate 4800
= 4 if Baud rate 2400
= 5 if Baud rate 1200
d = 0 if Data Format 8-N-1
= 1 if Data Format 7-E-2
= 2 if Data Format 7-O-2
ee = Osc. Adjust in hex (00 to FF)
ff = Slope Adjust times by 10 (00 to 10)
g = Always 0, unused
hh = LCD Contrast (0 to 30)
ii = LCD Brightness (0 to 30
