UT-4500 Series C- and Ku-Band Up Converters
Specifications

2.2.11 Phase Noise

2.2.11.1

UT-4505

Parameter
100 Hz
1 KHz
10 KHz
100 KHz
1 MHz
2.2.11.2 UT-4505/E, UT-4505/F, UT-4505/G, UT-4505/H,
UT-4505/I, UT-4505/J, UT-4505/K, UT-4505/M,
UT-4505/N
Parameter
100 Hz
1 KHz
10 KHz
100 KHz
1 MHz
2.2.11.3

UT-4514

Parameter
100 Hz
1 KHz
10 KHz
100 KHz
1 MHz
2.2.11.4

UT-4514/F, UT-4518, UT-4518/E

Parameter
100 Hz
1 KHz
10 KHz
100 KHz
1 MHz
Limit (dBc/Hz)
-80
-89
-95
-105
-120
Limit (dBc/Hz)
-69
-79
-89
-99
-109
Limit (dBc/Hz)
-72
-79
-89
-98
-110
Limit (dBc/Hz)
-66
-76
-86
-96
-106
2–11
MN/UT4500.IOM
Revision 3
Typical (dBc/Hz)
-83
-92
-97
-109
-124
Typical (dBc/Hz)
-72
-82
-92
-102
-112
Typical (dBc/Hz)
-79
-82
-92
-101
-114
Typical (dBc/Hz)
-69
-79
-89
-99
-109
