6.2 EMC and Environmental Type Tests
•
•
6.2

EMC and Environmental Type Tests

The RUGGEDCOM RSG908C has passed the following Electromagnetic Compatibility
(EMC) and environmental tests.
EMC Type Tests
61000-4-2
61000-4-3
61000-4-4
61000-4-5
61000-4-6
61000-4-8
61000-4-9
61000-4-11
36
EN 50121-3-2
Railway applications – Electromagnetic Compatibility – Rolling Stock Apparatus
EN 50155
Railway applications – Rolling stock – Electronic equipment
Test
IEC ESD
IEC Radiated RFI
IEC Burst (Fast Transient)
IEC Surge
IEC Induced (Conducted) RFI
IEC Magnetic Field
IEC Pulse Magnetic Field
IEC Voltage Dips and Interrupts
Description
Enclosure
Contact
Enclosure Air
Enclosure
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Earth
Ground Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Earth
Ground Ports
Enclosure
Ports
Enclosure
Ports
AC Power
Ports
Test Levels
± 8 kV
± 15 kV
20 V/m
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV Line-to-Ground
± 2 kV Line-to-Line
± 2 kV Line-to-Ground
± 1 kV Line-to-Line
± 4 kV Line-to-Ground
± 2 kV Line-to-Line
10 V
10 V
10 V
10 V
100 A/m Continuous
1000 A/m for 1 s
300 A/m
30% for 0.5 Cycles
Installation Manual, 04/2022, C79000-G8976-1404-11
Severity
Levels
4
4
4
4
4
4
4
3
4
3
3
3
3
4
RUGGEDCOM RSG908C
