To mount the device to a panel, do the following:
1.
2.
RUGGEDCOM RSG908C
Installation Manual, 04/2022, C79000-G8976-1404-11
Secure the mounting adapters to the top and bottom of the device using the
four M4 screws included with the device.
1
1
Screw (M4)
1
Panel Mount Adapter
2
Figure 2.4
Panel Mount Adapter Assembly
Prepare mounting holes in the panel where the device is to be installed.
2.4.2 Mounting the Device to a Panel
2
2
Installing the Device
11
