LO Power Supply Configurations
Figure 2.15
RUGGEDCOM RSG908C
Installation Manual, 04/2022, C79000-G8976-1404-11
-
+
Single LO DC Power Input
Configuration
2.6.2 Wiring Examples

Figure 2.16
Dual LO DC Power Input
Configuration
Installing the Device
-
+
-
+
19
