Industrial Electronic Devices
CHARACTERISTICS:
The "Modbus TCP Slave / Modbus Master – Converter" allows the following characteristics:
Triple isolation between RS232/RS485/RS422 - Power Supply, RS232/RS485/RS422- Ethernet, Power Supply - Ethernet;
Internal Ethernet switch;
Ethernet 10Base-T / 100Base-T, autosensing for Modbus TCP ;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC
Temperature range -40°C / +85°C [-40°F / +185°F];
This device is able to manage a maximum of ten simultaneous connections from Ethernet side.
It can be used in two operative ways:
In the "Routing Mode" the command Modbus is forwarded on the serial line using the same requested addresses.
In the "Natting Mode" the device addresses and data are altered through a translation table of the addresses.
CONFIGURATION:
You need Compositor SW67508 software on your PC in order to perform the following:
Define the parameters of Modbus TCP line;
Define the parameters of Modbus Serial line;
Update the device.
ADFweb.com S.r.l.
User Manual Modbus TCP Slave / Modbus Master
Document code: MN67508_ENG
Revision 1.100
Page 8 of 28
