Image Adjustment 2 Main Menu

Setting Name
Input
Vertical
R C V
Position
Horizontal
R C V
Position
Frequency
R
Phase
R
Restore Menu
R C V
Defaults
About the "Signal Specific" Setting Unit
For the items that have "Signal Specific" in the "Setting Unit" column of the above table, the setting is
saved for the specific type of signal (XGA/60Hz, SXGA/60Hz, etc.) that is being input when the setting
is performed, and not for a specific input source.

Volume Adjustment Main Menu

Setting Name
Input
Volume
R C V H D U N Source
Restore Menu
R C V H D U N Source
Defaults
Setting Unit
Signal
Use this sub-menu to adjust the vertical position of the input source
Specific
image within the projection area.
Signal
Use this sub-menu to adjust the horizontal position of the input
Specific
source image within the projection area.
Signal
When vertical bands appear in the projected image while RGB is
Specific
selected as the input source, it means that the frequency setting is
not correct. When this happens, use this setting to adjust the
frequency manually.
Important!
If, for some reason, your manual frequency settings cause the
image input from the computer to disappear from the
projection, you can press the [AUTO] key to perform an auto
adjust operation, which should cause the image to appear.
Signal
When there is flickering in the projected image while RGB is
Specific
selected as the input source, it means that the phase setting is not
correct. When this happens, use this setting to adjust the phase
manually.
Source
Use this sub-menu to return all of the sub-menu items on the Image
Specific
Adjustment 2 main menu to their initial default settings.
Restoring menu defaults will restore defaults for the current signal
type (XGA/60Hz, SXGA/60Hz, etc.) only.
Setting Unit
Use this sub-menu to adjust the volume level of the projector's
Specific
speaker.
Changing this setting when there is no input signal changes the
volume setting of the currently selected signal source.
Use this sub-menu to return Volume to its initial default setting.
Specific
Restoring menu defaults when there is no input signal will restore
defaults for the currently selected input source.
31
