Supported Signals

Important!
Even if a signal is listed in the table below, it does not guarantee that you will be able to display
its images correctly.

RGB Signal

Signal Name
VESA 640 × 480/60
640 × 480/72
640 × 480/75
640 × 480/85
800 × 600/56
800 × 600/60
800 × 600/72
800 × 600/75
800 × 600/85
1024 × 768/60
1024 × 768/70
1024 × 768/75
1024 × 768/85
1152 × 864/75
1280 × 768/60
1280 × 800/60
1280 × 960/60
1280 × 960/85
1280 × 1024/60
1280 × 1024/75
1280 × 1024/85
1360 × 768/60
1366 × 768/60
1400 × 1050/A
1440 × 900/60
1600 × 1200/60
1680 × 1050/60
Other 1152 × 864/70
1400 × 1050/B
*1 If these signals do not project correctly, change the "Option Settings 1
(page 35).
*2 If this signal does not project correctly, change the "Option Settings 1
(page 35).
Resolution
640 × 480
640 × 480
640 × 480
640 × 480
800 × 600
800 × 600
800 × 600
800 × 600
800 × 600
1024 × 768
1024 × 768
1024 × 768
1024 × 768
1152 × 864
1280 × 768
1280 × 800
1280 × 960
1280 × 960
1280 × 1024
1280 × 1024
1280 × 1024
*1
1360 × 768
*2
1366 × 768
*1
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1152 × 864
*1
1400 × 1050
52
Horizontal Frequency
(kHz)
31.5
37.9
37.5
43.3
35.2
37.9
48.1
46.9
53.7
48.4
56.5
60.0
68.7
67.5
47.8
49.7
60.0
85.9
64.0
80.0
91.1
47.7
47.7
65.3
55.9
75.0
65.3
64.0
64.0
Auto Adjust" setting to "2"
Auto Adjust" setting to "3"
Vertical Frequency
(Hz)
60
73
75
85
56
60
72
75
85
60
70
75
85
75
60
60
60
85
60
75
85
60
60
60
60
60
60
70
60
