3.3.

DisplayPort Connector

The DisplayPort connector on the front panel can also connect to VGA, DVI, and HDMI displays via DisplayPort to
VGA adapter cable, DisplayPort to DVI adapter cable, or DisplayPort to HDMI adapter cable.
Optional Adapter Cables
• Active DisplayPort to HDMI adapter cable (P/N: 30-01119-0010)
• Active DisplayPort to DVI adapter cable (P/N: 30-01120-0010)
• Active DisplayPort to VGA adapter cable (P/N: 30-01121-0010)
3.4.

USB 3.2 Gen2 Type A ports

There are 4x USB 3.2 Gen2 Type A ports on the front panel.
Speed: 10 Gbps
Voltage: 5 V
Current: 900 mA
Inrush current: 100 mA or 44 Ohm || 10 µF
Protection: TPS2553, 910 mA min., 1010 mA max.
3.5.

USB 3.2 Gen2 Type C ports

There are 2x USB 3.2 Gen2 Type C ports on the rear panel (supporting DP1.4 dsiplay output).
Pinouts and Signal Descriptions

Figure 8: DisplayPort Connector

Pin
Signal
1
CN_DDPx0+
2
GND
3
CN_DDPx0-
4
CN_DDPx1+
5
GND
6
CN_DDPx1-
7
CN_DDPx2+
8
GND
9
CN_DDPx2-
10
CN_DDPx3+

Table 7: DisplayPort Connector Pin definition

Pin
Signal
11
GND
12
CN_DDPx3-
13
CN_DDPx_AUX_SEL
14
CN_DDPx_CONFIG2
15
CN_DDPx_AUX+
16
GND
17
CN_DDPx_AUX-
18
CN_DDPx_HPD
19
GND
20
+V3.3_DDPx_PWR_CN
11
