3.10. Onboard Headers

Refer to 2.6.1 Carrier Board Connector Locations on page 6 for onboard header locations.
Header
USB 2.0 Pin Header
COM1 Pin Header
Power Management Header
Pinouts and Signal Descriptions
Pin Definition
DUMMY
RRXD 1
DDTR# 1
DDSR# 1
CCTS # 1
1
R R TS# 1
G N D
TTXD 1
DDCD# 1
1
HDLED+
HDLED-
GND
RESET#
DUMM Y

Table 12: Onboard Header Pin Definitions

Function
9-pin USB 2.0 header
(USB2_7_8)
RS-232 COM1 port header
RRI# 1
Header for system front panel
functions (PANEL1, to COM2
on right side I/O)
PLED+
PLED-
PWRBT N#
GND
17
