3.6.

RS-232 Serial Port Header (COM 1)

There is a RS232 DB9 port on the right side panel (labeled "COM1").
12

Figure 9: RS-232 DB9 Serial Port

Pin
Signal
1
DDCD#1
2
RRXD1
3
TTXD1
4
DDTR#1
5
GND

Table 8: RS-232 Serial Port Pin Definition

Pin
Signal
6
DDSR#1
7
RRTS#1
8
CCTS#1
9
RRI#1
Pinouts and Signal Descriptions
