2.6.

System Layout

2.6.1.
Carrier Board Connector Locations
6
G
F

Figure 2 -Carrier Board Connectors (top)

M.2 Key-M socket for NVMe SSD
A
(Top, M2_M1)
M.2 Key-E socket for M.2 2230 Wi-Fi card
B
(Bottom, M2_E1)
C
USB 2.0 connector (USB2_7_8)
COM port header
D
(to RS-232 "COM 1" on right side I/O)
E
Clear CMOS jumper (CLRCMOS1)
Power mode jumper (SIO_AT1)
F
(open: ATX; shorted: AT)
Power Management Header (PANEL1)
G
(to COM2 on right side I/O)

Table 1: Carrier Board Connector Legend (top)

A
B
D
C
E
