72
Display
Display 25
Display 26
Display 27
*Note: "Digital Temp Sensor Value*" must be multiplied by the appropriate VBIT from table 14.2 in order to create a displayable Value*.
Resolution
Input Voltage Range
0-5V
5-14V
14-30V
30-70V
70-90V
Description
Digital T emp Sensor 27 Minor Under, Minor Over
Digital T emp Sensor 27 Major Under, Major Over
Digital T emp Sensor 27 - Sensor not Detected
Digital T emp Sensor 27 Range
Digital T emp Sensor 27 Polarity
Digital T emp Sensor 27 Value*
Digital T emp Sensor 28 Minor Under, Minor Over
Digital T emp Sensor 28 Major Under, Major Over
Digital T emp Sensor 28 - Sensor not Detected
Digital T emp Sensor 28 Range
Digital T emp Sensor 28 Polarity
Digital T emp Sensor 28 Value*
Digital Temp Sensor 29 Minor Under, Minor Over
Digital Temp Sensor 29 Major Under, Major Over
Digital Temp Sensor 29 - Sensor not Detected
Digital Temp Sensor 29 Range
Digital Temp Sensor 29 Polarity
Digital Temp Sensor 29 Value*
Digital Temp Sensor 30 Minor Under, Minor Over
Digital Temp Sensor 30 Major Under, Major Over
Digital Temp Sensor 30 - Sensor not Detected
Digital Temp Sensor 30 Range
Digital Temp Sensor 30 Polarity
Digital Temp Sensor 30 Value*
Digital T emp Sensor 31 Minor Under, Minor Over
Digital T emp Sensor 31 Major Under, Major Over
Digital T emp Sensor 31 - Sensor not Detected
Digital T emp Sensor 31 Range
Digital T emp Sensor 31 Polarity
Digital T emp Sensor 31 Value*
Digital T emp Sensor 32 Minor Under, Minor Over
Digital T emp Sensor 32 Major Under, Major Over
Digital T emp Sensor 32 - Sensor not Detected
Digital T emp Sensor 32 Range
Digital T emp Sensor 32 Polarity
Digital T emp Sensor 32 Value*
VBIT Values used for creating appropriate cell Values.
Port
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
99
VBIT
.0015V
.0038V
.0081V
.0182V
.0231V
Address
Point
1
1, 2
1
3, 4
1
5
1
9-11
1
13
1
17-32
1
33, 34
1
35, 36
1
37
1
41-43
1
45
1
49-64
1
1, 2
1
3, 4
1
5
1
9-11
1
13
1
17-32
1
33, 34
1
35, 36
1
37
1
41-43
1
45
1
49-64
1
1, 2
1
3, 4
1
5
1
9-11
1
13
1
17-32
1
33, 34
1
35, 36
1
37
1
41-43
1
45
1
49-64
Accuracy
+/- .05V
+/- .14V
+/- .30V
+/- .70V
+/- .90V
