SNMP Trap Server IP
Trap Port No.
Trap Community
Trap Type
SNMPv3 User
Relay Notification Field
Select Relay to Latch

11.7.2 Schedule

The notifications scheduling menu is where you will tell the NetGuardian exactly which days and times you want to
receive alarm notifications. You set 2 different schedules for each.
Days of the week
Any Time
Notification Time
SNMP Notification
The SNMP trap manager's IP address.
The SNMP port (UDP port) set by the SNMP trap manager to receive
traps, usually set to 162.
Community name for SNMP TRAP requests.
Indicate whether you would like to send SNMP v1, v2c, or v3 traps.
Select the user. User is configured in the SNMP menu.
Editing SNMP notification settings
SNMP Notification
Select the number of the relay (1-4 or 1-8, depending on your build
option) you want to latch upon the alarm triggering.
The Schedule creation screen
Notification Scheduling
From either Schedule 1 or 2, check which days you want to receive notifications.
Select this is if you want to receive alarm notifications at any time for the day(s)
you've selected.
Tells the unit to only send notifications during certain hours on the day(s) you've
selected.
