Installation Instructions
Attention Installer:
Please read these instructions carefully to prevent missing important steps.
Improper installations may result in damage to the lock and void the factory warranty.
The accuracy of the door preparation is critical for proper functioning and security of this lock.
Misalignment can cause premature wear and a lessening of security.
For specific security information, please contact your local ASSA ABLOY
Door Security Solutions sales consultant or call 800-810-9473.
Copyright © 2016, 2019, 2021-23 Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written permission of Sargent
Manufacturing Company is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents.
HID, iCLASS, and Edge are trademarks or registered trademarks of HID Global Corporation.
IN
IN120 Wi-Fi
IN220 PoE
PE80 Series and
80 Series Exit Devices
includes Rim & Mortise
A8185-6
09/23
