Appendix C.1. Prestige Modbus RTU Mappings to BACnet MS/TP, BACnet/IP, Metasys N2 and LonWorks

Point Name
CH Demand
Maximum Firing Rate
CH Setpoint
CH1 Max Setpoint
DHW Storage Setpoint
PC Manual Mode
DHW Mode
CH Mode
Freeze Protection Mode
Flame Present
CH(1) Pump
DHW Pump
System / CH2 Pump
Lockout Code Type
Lockout Code
Lockout Status
Boiler Supply Temp / Sys
Temp
Boiler Return Temp
DHW Storage Temp
Boiler Flue Temp
Outdoor Temp
Flame Ionization Current
Boiler / Cascade Firing
Rate
Boiler Setpoint
Note: See Modbus Interface in the Prestige Control Application Supplement – TriMax for additional information.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web: www.protocessor.com
BACnet BACnet
N2
Object Object Data
Type ID Type
AV 1 AO
AV 2 AO
AV 3 AO
AI 4 AI
AI 5 AI
BI 6 DI
BI 7 DI
BI 8 DI
BI 9 DI
BI 10 DI
BI 11 DI
BI 12 DI
BI 13 DI
AI 14 AI
AI 15 AI
AI 16 AI
AI 17 AI
AI 18 AI
AI 19 AI
AI 20 AI
AI 21 AI
AI 22 AI
AI 23 AI
AI 24 AI
Email: support@protocessor.com
N2
Point Lon Name
Address
1 nvi/nvoCHDemand
2 nvi/nvoMaxFirRate
3 nvi/nvoCH1SP
4 nvoCH1MaxSP
5 nvoDHWStorageSP
6 nvoPCManualMode
7 nvoDHWMode
8 nvoCHMode
9 nvoFrzProtctMod
10 nvoFlamePresent
11 nvoCHPmp
12 nvoDHWPmp
13 nvoSysCH2Pmp
14 nvoLckotCdType
15 nvoLckotCd
16 nvoLckotStatus
17 nvoBlrSupTmp
18 nvoBlrRetTmp
19 nvoDHWStrgTmp
20 nvoBlrFlueTmp
21 nvoOutdoorTmp
22 nvoFlmIonCrrt
23 nvoBlrCscFirRat
24 nvoBlrSP
Page 33 of 40
Lon SNVT
SNVT_count_inc_f
SNVT_lev_percent
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_switch
SNVT_count_inc_f
SNVT_count_inc_f
SNVT_count_inc_f
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_temp_p
SNVT_count_inc_f
SNVT_lev_percent
SNVT_temp_p
