- Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8700-20 Profibus DP APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after May 1, 2001 Driver Version: 1.02 Document Revision: 4...
-
Page 2: Table Of Contents
FieldServer as a Profibus Master ...20 Appendix C.3. Error and Informational Messages on Ruinet E and F screens ...21 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Table of Contents Party Equipment...4... -
Page 3: Profibus Dp Description
The tool provided on the SST CD can be used to create this file. As a slave, the Profibus DP driver allows the FieldServer to be a single slave station to another master. This slave is capable of transferring 244 bytes of input and 244 bytes of output to the other master. -
Page 4: Driver Scope Of Supply
Hardware PART # 2.2.2. Software PART # FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Description Profibus ISA card SST CD “For Profibus Interface Cards” Profibus connector without terminating resistor Driver Manual. -
Page 5: Hardware Connections
SST CD. WARNING: Improper cabling can cause physical layer problems that are hard to diagnose. The FieldServer is connected to the Profibus DP as shown in the connection drawing below: Configure the Profibus DP according to manufacturer’s instructions... -
Page 6: Profibus Master Configuration
3.3. Profibus Master Configuration If using the FieldServer as a Profibus master, provide a configuration file to fully describe the network connected to the FieldServer. The Profibus driver will accept a 2BF file or a BSS file. The 2BF file is created using COM PROFIBUS from Siemens. The BSS file is created using the SST Profibus Configuration tool. -
Page 7: Configuring The Fieldserver As A Profibus Dp Master
// Common information FieldServer Title, Profibus DP Master, 4.2. Data Arrays/ Descriptors Data Arrays are the neutral data buffers used by the FieldServer to pass data between communications drivers, and are defined as follows: Section Title Data_Arrays Column Title Data_Array_Name... -
Page 8: Client Side Connection Descriptions
FieldServer Example Client Side Nodes Nodes Node_Name, Node_ID, PDP_01, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Legal Values Prof_DP Profibus_DP Protocol Profibus_DP Legal Values... -
Page 9: Client Side Map Descriptors
BYTE_IN_01, DA_BO_01, BIT_IN_01, DA_DO_01, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Legal Values Up to 32 alphanumeric characters One of the Data Array names from “Data Array”... -
Page 10: Creating The Network Configuration File For The Master
Click OK to close the Master window. 3) Right-click on the PROFIBUS_DP icon and choose Properties to configure the network. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com... - Page 11 Slave device; otherwise the Master will not connect to the Slave. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com...
- Page 12 Page 12 of 22 6) Right-click on the PFB_ISA_MASTER Icon and select Export Binary and create a file called bridge.bss. Download this file to your FieldServer using Ruinet and restart the FieldServer. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com...
-
Page 13: Configuring The Fieldserver As A Profibus Dp Slave Only
// Common information FieldServer Title, Profibus DP Slave, 5.2. Data Arrays/ Descriptors Data Arrays are the neutral data buffers used by the FieldServer to pass data between communications drivers, and are defined as follows: Section Title Data_Arrays Column Title Data_Array_Name... -
Page 14: Server Side Connection Descriptions
Example Client Side Nodes Nodes Node_Name, Node_ID, PDP_01, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Legal Values Prof_DP Profibus_DP 9600, 19200, 93.75K, 187.5K, 500K, 750K, 1.5M, 3M, 6M,... -
Page 15: Server Side Map Descriptors
DA_BI_01, BIT_IN_0,1 DA_DI_01, FLOAT_OUT_01, DA_FO_01, INT_OUT_01, DA_AO_01, BYTE_IN_01, DA_BO_01, BIT_IN_01, DA_DO_01, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com DP_Buffer being accessed, Data_Array_Offset, Function, Node_Name, RDBC, PDP_01, RDBC,... -
Page 16: Appendix A. Special Driver Parameters
Appendix A. Special Driver Parameters Appendix A.1. DP_Buffer Within the Profibus DP card, the FieldServer can access data from two distinct buffers. The Input buffer is the data that is sent from the slave to master. The Output buffer is the data sent from the master to the slave. -
Page 17: Appendix B. Driver Notes
RDBC Input WRBC The diagram below explains the data flows for both buffers when using the FieldServer as a DP Master: Note that for the Input buffer, the data is coming from the external DP Slave and is transferred into the DP Master card’s internal input buffer. The Map Descriptor being of the RDBC function ( Read Data Block Continuous ) transfers the data from the card buffer into the FieldServer’s Data Array packing it correctly according to the specified DP_Type. - Page 18 Note: The Node ID determines to which external DP slave the data will be sent or fetched from. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com Data Array...
-
Page 19: Appendix C. Troubleshooting
Profibus Master configuration. This file must not exist in applications where FieldServer is being used as a slave. o To check for the file, try uploading the file from the FieldServer using the RUI Utility. If it uploads successfully, then it will need to be deleted. See the FieldServer Utilities manual for instructions on how to do this. -
Page 20: Appendix C.2. Fieldserver As A Profibus Master
The Profibus card may be faulty. • If this is the case, then there will be an error message in the FieldServer RUI error screen indicating that the card could not be reached. Check for this message. If it is there, try opening up the FieldServer and re-seating the card. -
Page 21: Appendix C.3. Error And Informational Messages On Ruinet E And F Screens
Appendix C.3. Error and Informational Messages on Ruinet E and F screens Master Mode not enabled This message means that the FieldServer is not set up to be a Profibus DP Master. This indicates that the FieldServer did not find a Master scanner file, (bridge.bss). This message is normal if you configured the FieldServer to be a DP Slave. - Page 22 FS-8700-20 Profibus DP Driver Manual Page 22 of 22 THIS PAGE INTENTIONALLY LEFT BLANK FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldServer.com...
