Triangle Tube's ProtoNode Startup Guide
4

BACNET/IP AND MODBUS TCP: CHANGE THE PROTONODE IP ADDRESS

4.1

Connect the PC to ProtoNode via the Ethernet Port

Connect a standard CAT5 Ethernet cable (Straight through or Cross-Over) between the PC and
ProtoNode
The Default IP Address of ProtoNode is 192.168.1.24, Subnet Mask is 255.255.255.0. If the PC and
ProtoNode are on different IP Networks, assign a static IP Address to the PC on the 192.168.1.xxx
network
For Windows XP:
Go to
Right-click on Local Area Connection > Properties
Highlight
For Windows 7:
Go to
>
Right-click on Local Area Connection > Properties
Highlight
For Windows XP and Windows 7, select: Use the following IP address
Click
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web: www.protocessor.com

Figure 16: Ethernet Port Location

>
>
>
>
>
twice
Email: support@protocessor.com
Ethernet
>
>
Page 19 of 40
