FieldServer Protocessor ProtoNode FPC-N34 Startup Manual page 29

Triangle Tube's ProtoNode Startup Guide
• For Windows XP and Windows 7, select: Use the following IP address
• Click
Double click on the FST Diag Utility
•
Step 1: Select a Field Server IP Address
•
• The IP address can be entered manually or selected by clicking on button 1 using the Utility
Press here to retrieve the IP address.
Step 2: Take a Log
•
Press the Take Log button. While the Utility runs a few DOS prompts will flash across the monitor. Don't
•
click or type anything in to these DOS prompts. This step may take a few minutes depending on the
chosen Log Type and computer speed. When the Utility is finished you will be presented with a log of
events that have occurred.
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web: www.protocessor.com
twice
Type in the ProtoNode IP address
Default IP Address is 192.168.1.24
Locate where the log is saved on the PC
Select a log type.
Press the Take Log button.
Email: support@protocessor.com
Page 29 of 40
