Triangle Tube's ProtoNode Startup Guide
6.2

CAS BACnet Setup

These are the instructions to set CAS Explorer up for the first time on BACnet MS/TP and BACnet/IP.
6.2.1

CAS BACnet MS/TP Setup

Using the Serial or USB to RS-485 converter, connect it to your PC and the 3 Pin BACnet MS/TP
connector on ProtoNode FPC-N34.
In CAS Explorer, do the following:
o
Click on settings
Check the BACnet MSTP box and uncheck the BACnet/IP and BACnet Ethernet boxes
o
o
Set the BACnet MSTP MAC address to 0
Set the BACnet MSTP Baud Rate to 38400
o
o
Click Ok
o
On the bottom right-hand corner, make sure that the BACnet MSTP box is green
o
Click on discover
o
Check all 4 boxes
o
Click Send
6.2.2

CAS BACnet BACnet/IP Setup

See Section 4.1 to set the IP address and subnet of the PC that will be running the CAS Explorer.
Connect a standard CAT5 Ethernet cable (Straight through or Cross-Over) between the PC and
ProtoNode
In CAS Explorer, do the following:
Click on settings
o
o
Check the BACnet/IP box and uncheck the BACnet MSTP and BACnet Ethernet boxes
In the "Select a Network Device" box, select the network card of the PC by clicking on it
o
o
Click Ok
o
On the bottom right-hand corner, make sure that the BACnet/IP box is green
Click on discover
o
o
Check all 4 boxes
o
Click Send
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web: www.protocessor.com
Email: support@protocessor.com
Page 26 of 40
