Vehicle Connections - Directed DIRECTECHS DB3 Installation Manual

Vehicle connections

The connection information listed below is specific to the 2010 Jeep Liberty. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
9 403.CHRYSLER 7.34 2010 Jeep Liberty
©2022 VOXX•DEI LLC. All rights reserved.
Description
No Connection
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
(DATA) FT CAN High
(DATA) FT CAN Low
Relay N.O. No Connection
Relay COM Ignition Output
Relay N.C. Ignition Output
Relay N.C. No Connection
Relay COM No Connection
Relay N.O. No Connection
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) W2W Only - E-Brake Output
No Connection
(-) W2W Only - Door Output
(-) W2W Only - Trunk Output
[1]
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
No Connection
(MUX) Ignition Output
(MUX) Ignition Output
(-) RAP Off Output
No Connection
(-) W2W Only - Hood Switch Input
Description
Connects To
Wire Location
No Connection
No Connection
Sentry Key Module on ignition switch, black 8 pin plug, pin 6
Sentry Key Module on ignition switch, black 8 pin plug, pin 7
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Sentry Key Module on ignition switch, black 8 pin plug, pin 5
Connects To
Wire Location
Remote Starter
No Connection
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
Sentry Key Module on ignition switch, black 8 pin plug, pin 1
Sentry Key Module on ignition switch, black 8 pin plug, pin 1
driver kick, door harness
No Connection
Remote Starter
Connects To
Wire Location
(+/-) Wire Color
data white/black (CAN C bus)
data white/lt. blue (CAN C bus)
+ red (20A)
(chassis ground)
(+/-) Wire Color
MUX violet/brown
MUX violet/brown
- violet
(+/-) Wire Color
