Directed DIRECTECHS DB3 Installation Manual page 10

Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Ground
Hood Pin
Ignition
Parking Lights
Tachometer
10 403.CHRYSLER 7.34 2010 Jeep Liberty
©2022 VOXX•DEI LLC. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
(-) W2W Only - Aux1 Input
(-) W2W Only - Aux2 Input
No Connection
(+) W2W Only - Pk Light Input
(+) W2W Only - Starter Input
(+) W2W Only - Ignition Input
(-) W2W Only - Ground When Running (Status) Input
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
driver kick, gray 43 pin plug, pin 4
hood switch or underhood fuse box, gray 16 pin plug, pin 3
Sentry Key Module on ignition switch, black 8 pin plug, pin 3
driver kick, harness to rear
any fuel injector, black 2 pin plug, pin 2
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
Remote Starter
Remote Starter
Remote Starter
(+/-)
+
-
+
+
ac
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
Wire Color
red (30A)
(chassis ground)
violet/lt. blue
pink/white
white/violet
bn/yl, bn/dk bu, bn/lt bu, bn/tn, bn/og, or bn/pu
