Vehicle connections

The connection information listed below is specific to the 2013 Ford Fusion. Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) CAN 2 Low (w/ OEM Remote Start) or
(Data) CAN 3 (w/o OEM Remote Start)
H1/2 Tan/Black (Data) CAN 2 High (w/ OEM Remote Start) or
(Data) CAN 3 (w/o OEM Remote Start)
H1/3 Orange/Brown (Data) HS CAN Low 1
H1/4 Orange/Green (Data) HS CAN High 1
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black No Connection
H1/8 Yellow/Black No Connection
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Factory Alarm Arm Output
H2/2 Blue/White
(-) Ground When Armed (GWA) Output
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Trunk Release Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
H2/7 White (+) AUX 1 Output
H2/8 Violet/Black (+) AUX 2 Output
H2/9 Dk. Blue/Black (-) Unlock Output
H2/10 Lt. Blue/Black (-) Factory Alarm Disarm Output
H2/11 Brown/Red
(+) Siren Output
H2/12 Pink (+) Ignition Sense Input
12 933.FORD11 2.07.198.12 2013 Ford Fusion
©2023 Directed. All rights
Connects To
Wire Location
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin
22
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin
17
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin
23
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin
18
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin
19
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin
20
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
[3] Starter:
ignition switch, black 7 pin plug, pin 7
Ignition:
ignition switch, black 7 pin plug, pin 1
Must use a 1N4002 diode or larger.
No Connection
release switch, black or brown 6 pin plug, pin 6
horn switch, black 12 pin plug, pin 1 --or-- BCM/dash fuse box, black
52 pin plug (G), pin 18
No Connection
No Connection
No Connection
No Connection
No Connection
[2] The siren is ONLY required when enabling the security features during
module flashing.
No Connection
(+/-) Wire Color Connection
data violet/orange (MS CAN) Mandatory
data gray (HS2 CAN)
data gray/orange (MS CAN) Mandatory
data green (HS2 CAN)
data white (HS CAN) Mandatory
data blue or white/blue (HS Mandatory
CAN)
(+/-) Wire Color Connection
+ blue/white Security Only
+ white/orange
- gray/yellow Mandatory
- green/white Optional
Security Only
