Hardware Installation and Reference Guide
Storage humidity: 5% to 95% RH
Altitude 0 to 5000 m (0 to 3.11 miles)
Speed adjustment and fault alarm
Fan
Temperature
Supported
Alarm
EMI Standard GB9254-2008CLASS A
Safety Standard GB4943-2011
Dimensions
440 mm x 340 mm x 44 mm (17.32 in. x 13.39 in. x 1.73 in.)
(W x D x H)
Weight 4.4 kg (9.70 lbs.)

Product Appearance

The S5760C-24GT8XS-X
port, 1 USB port, and 1 Console port on the front panel, 2 power supply module slots and 1 expansion slot on the back
panel.
Figure 1-1 Appearance of RG-S5760C-24GT8XS-X

Front Panel

Figure 1-2 Front Panel of RG-S5760C-24GT8XS-X
V1.X has 2 fans, and V2.X has 3 fans .
Ethernet switch provides 24 10/100/1000Base-T Ethernet ports, 8 10GE SFP+ ports, 1 MGMT
4
Overview
